Global TTC 1 & 2 Wire Braid Steel Crimp Fitting, M22 x 1.5 Female German DIN 3902 24 deg Flare Light Duty Swivel, -08 Hose, 45 deg Elbow

Application General purpose low and medium pressure hydraulics. Use H277 or H435 where shock hazards exist	D 52	Drop Dimension 0.81	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Gender 1 13553	End Size 1 27	End Size 2 0.50	End Type 1 Metric	End Type 2 Line/Hose/Tube	H 21.5 mm	Hose Size -08	Mandrel Required No	Supplier Part Number 1A12DLA8	Thread 1 M22 x 1.5	Thread Sealant No	Torque Rating 55-70 LB/FT	Torque Rating 55-70 LB/FT	Alternate Part Numbers Alternate Part Number C1ES65, Alternate Part Number MI-03065180, Alternate Part Number MINO-00015J51538	Tube O.D. 15	Product Weight 0.32 lbs

Product Questions & Answers 2

Product Questions & Answers

torque spec on this fitting -- is 55 to 70 lb/ft the final assembly number or just a starting point?

Question by: Marvin R on Mar 14, 2026, 4:46 PM

That range, 55 to 70 lb/ft, is the rated torque for achieving a proper seal and holding strength on this fitting. It's not a break-in spec or a starting point. Hit somewhere in that window and you're good. Going above it won't buy you anything and risks damaging the swivel or the seating surface on the DIN 24-degree flare.

Answer by: Customer Support on Mar 16, 2026, 6:27 AM

got a -08 hose and need a 45 elbow with a metric female swivel, is this the one with M22 x 1.5 threads?

Question by: Freddie J on Jan 25, 2026, 10:20 AM

For a metric female swivel in a 45 degree elbow, this fitting matches M22 x 1.5 on the female end and is built to crimp onto a -08 hose.

Answer by: Customer Support on Jan 26, 2026, 2:20 PM

Similar Products

Model Number	Thread 1	Tube O.D.	Hose Size	D	H
1A16DLA10	M26 x 1.5	18	-10	59	27.5 mm
1A10DLA6	M18 x 1.5	12	-06	44.5	20.5 mm
1A12DLA8	M22 x 1.5	15	-08	52	21.5 mm
1A6DLA4	M14 x 1.5	8	-04	39	17.5 mm
1A8DLA6	M16 x 1.5	10	-06	41.5	19 mm
