Global TTC 1 & 2 Wire Braid Steel Crimp Fitting, M16 x 1.5 Female German DIN 3902 24 deg Flare Light Duty Swivel, -06 Hose, 45 deg Elbow

Application General purpose low and medium pressure hydraulics. Use H277 or H435 where shock hazards exist	D 41.50	Drop Dimension 0.75	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Gender 1 13553	End Size 1 0.50	End Size 2 0.38	End Type 1 Metric	End Type 2 Line/Hose/Tube	H 19 mm	Hose Size -06	Mandrel Required No	Supplier Part Number 1A8DLA6	Thread 1 M16 x 1.5	Thread Sealant No	Torque Rating 33-40 LB/FT	Torque Rating 33-40 LB/FT	Alternate Part Numbers Alternate Part Number C1HK66	Tube O.D. 10	Product Weight 0.18 lbs

Product Questions & Answers 3

Product Questions & Answers

trying to swap out a crimp end on a -06 hose. is this the 45 elbow with the M16 x 1.5 female swivel and the 24 degree DIN light flare?

Question by: Neil B on Sep 2, 2025, 3:02 PM

You are looking at a -06 hose crimp fitting with a 45 degree elbow and an M16 x 1.5 female German DIN 3902 24 degree flare light duty swivel end. It also calls out a 10 mm tube O.D. on the DIN flare side.

Answer by: Customer Support on Sep 4, 2025, 8:15 AM

what hose size does this fitting work with, and is it gonna hold up in a system that sees some shock loading?

Question by: Stan S on Jul 20, 2025, 9:49 AM

Sized for -06 hose, and it's rated for use with H277 or H435 hose specifically in applications where shock hazards are a concern. Those hose types are the recommended pairing when your system sees pressure spikes or vibration. The fitting itself covers general-purpose low and medium pressure hydraulic work, so as long as you're in that range and running the right hose, you're set up properly.

Answer by: Customer Support on Jul 22, 2025, 6:11 AM

Is this here fitting good for somethin' like a hydraulic lift on a trailer?

Question by: Steve C on Dec 11, 2025, 2:19 PM

For general-purpose, low to medium pressure hydraulic systems, this Aeroquip TTC fitting should do the trick. Just make sure your setup matches the fitting's specifications for hose size and thread type.

Answer by: Customer Support on Dec 13, 2025, 7:14 AM

Similar Products

Model Number	Thread 1	Tube O.D.	Hose Size	D	H
1A16DLA10	M26 x 1.5	18	-10	59	27.5 mm
1A10DLA6	M18 x 1.5	12	-06	44.5	20.5 mm
1A12DLA8	M22 x 1.5	15	-08	52	21.5 mm
1A6DLA4	M14 x 1.5	8	-04	39	17.5 mm
1A8DLA6	M16 x 1.5	10	-06	41.5	19 mm
