Global TTC 1 & 2 Wire Braid Steel Crimp Fitting, 1-5/16-12 Female JIC 37 deg Flare Swivel, -16 Hose, 90 deg Elbow

Application General purpose low and medium pressure hydraulics. Use H277 or H435 where shock hazards exist	D 2.20	Drop Dimension 2.39	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Gender 1 13553	End Size 2 1	End Type 1 JIC 37	End Type 2 Line/Hose/Tube	H 2.39 in	Hex Size 2 0.50	Hose Size -16	Mandrel Required No	Supplier Part Number 1AA16FJB16	Thread 1 1-5/16-12	Thread Sealant No	Torque Rating 117-125 LB/FT	Torque Rating 117-125 LB/FT	Alternate Part Numbers Alternate Part Number C1AP68, Alternate Part Number MI-00302143, Alternate Part Number MINO-00015F50885	Product Weight 1.04 lbs

Product Questions & Answers 1

Product Questions & Answers

trying to swap out an old 90 elbow, is this one the female JIC swivel with 1-5/16-12 threads for a -16 hose?

Question by: Randy G on Aug 27, 2025, 7:57 AM

You are looking at a 90 degree elbow crimp fitting with a 1-5/16-12 female JIC 37 degree flare swivel on one end and a -16 hose end on the other. It is part of the Aeroquip TTC steel crimp fitting line.

Answer by: Customer Support on Aug 28, 2025, 7:26 PM

Similar Products

Model Number	Thread 1	Hose Size	D	H
1AA10FJB10	7/8-14	-10	1.55	1.19 in
1AA10FJB8	7/8-14	-08	1.61	1.19 in
1AA12FJB10	1-1/16-12	-10	2.16	1.8 in
1AA12FJB12	1-1/16-12	-12	2.17	1.8 in
1AA16FJB16	1-5/16-12	-16	2.2	2.39 in
1AA4FJB4	7/16-20	-04	0.92	0.68 in
1AA6FJB4	9/16-18	-04	1.08	0.84 in
1AA6FJB6	9/16-18	-06	1.22	0.84 in
1AA8FJB6	3/4-16	-06	1.42	1.09 in
1AA8FJB8	3/4-16	-08	1.42	0.84 in
1AA20FJB20	1-5/8-12	-20	2.52	2.75 in
1AA16FJB12	1-5/16-12	-12	2.18	2.39 in
1AA24FJB24	1-7/8-12	-24	2.81	3.17 in
1AA4FJB6	7/16-20	-06	0.98	0.68 in
1AA5FJB4	1/2-20	-04	1	0.76 in
