Global TTC 1 & 2 Wire Braid Steel Crimp Fitting, 9/16-18 Female JIC 37 deg Flare Swivel, -06 Hose, 90 deg Elbow

Application General purpose low and medium pressure hydraulics. Use H277 or H435 where shock hazards exist	D 1.22	Drop Dimension 0.85	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Gender 1 13553	End Size 1 0.56	End Size 2 0.38	End Type 1 JIC 37	End Type 2 Line/Hose/Tube	H 0.84 in	Hose Size -06	Mandrel Required No	Supplier Part Number 1AA6FJB6	Thread 1 9/16-18	Thread Sealant No	Torque Rating 20-22 LB/FT	Torque Rating 20-22 LB/FT	Alternate Part Numbers Alternate Part Number C1AQ34, Alternate Part Number MI-00302135, Alternate Part Number MINO-00015F50877	Product Weight 0.17 lbs

Product Questions & Answers 2

Product Questions & Answers

got a -06 hose and need a 90 to clear a tight spot. is this the one with the swivel jic end?

Question by: Larry R on Mar 15, 2026, 7:18 AM

For a -06 hose, it matches up as a 90 degree elbow crimp fitting with a female JIC 37 degree flare swivel on the threaded end. The thread on that JIC end is 9/16-18.

Answer by: Customer Support on Mar 17, 2026, 7:09 AM

Will this fitting hold up okay in a hydraulic system that sees some pretty decent shocks now and then?

Question by: Daryl B on May 27, 2025, 8:13 PM

This crimp fitting is designed for general-purpose, low and medium-pressure hydraulic systems, and is specifically optimized for use with H277 or H435 hoses in environments where shock hazards are present.

Answer by: Customer Support on May 29, 2025, 9:50 AM

Similar Products

Model Number	Thread 1	Hose Size	D	H
1AA10FJB10	7/8-14	-10	1.55	1.19 in
1AA10FJB8	7/8-14	-08	1.61	1.19 in
1AA12FJB10	1-1/16-12	-10	2.16	1.8 in
1AA12FJB12	1-1/16-12	-12	2.17	1.8 in
1AA16FJB16	1-5/16-12	-16	2.2	2.39 in
1AA4FJB4	7/16-20	-04	0.92	0.68 in
1AA6FJB4	9/16-18	-04	1.08	0.84 in
1AA6FJB6	9/16-18	-06	1.22	0.84 in
1AA8FJB6	3/4-16	-06	1.42	1.09 in
1AA8FJB8	3/4-16	-08	1.42	0.84 in
1AA20FJB20	1-5/8-12	-20	2.52	2.75 in
1AA16FJB12	1-5/16-12	-12	2.18	2.39 in
1AA24FJB24	1-7/8-12	-24	2.81	3.17 in
1AA4FJB6	7/16-20	-06	0.98	0.68 in
1AA5FJB4	1/2-20	-04	1	0.76 in
