Global TTC 1 & 2 Wire Braid Steel Crimp Fitting, M20 x 1.5 Female German DIN 3902 24 deg Flare Heavy Duty Swivel, -06 Hose, 45 deg Elbow

Application General purpose low and medium pressure hydraulics. Use H277 or H435 where shock hazards exist	D 43	Drop Dimension 0.68	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Gender 1 13553	End Size 1 0.50	End Size 2 0.38	End Type 1 Metric	End Type 2 Line/Hose/Tube	H 19 mm	Hose Size -06	Mandrel Required No	Supplier Part Number 1A8DSA6	Thread 1 M20 x 1.5	Thread Sealant No	Torque Rating 52-66 LB/FT	Torque Rating 52-66 LB/FT	Alternate Part Numbers Alternate Part Number C1GA91	Tube O.D. 12	Product Weight 0.22 lbs

Product Questions & Answers 3

Product Questions & Answers

trying to replace a bent fitting, is this the one with M20 x 1.5 female threads and for -06 hose?

Question by: Gary B on Jul 25, 2025, 12:42 PM

It matches an M20 x 1.5 metric female end on one side and a -06 hose size on the hose end, with a 45 degree elbow body.

Answer by: Customer Support on Jul 26, 2025, 3:03 PM

What kind of pressure is this fitting good for?

Question by: Warren H on Aug 13, 2025, 3:45 PM

This steel crimp fitting is engineered for general-purpose low and medium pressure hydraulics.

Answer by: Customer Support on Aug 14, 2025, 4:48 PM

does this fitting work with H277 hose in a setup where there's some shock load involved, or is that pushing it for this type of crimp fitting?

Question by: Earl W on Jun 23, 2025, 3:11 PM

H277 is actually one of the hoses called out specifically for shock hazard applications with this fitting, so you're in good shape there. H435 is the other compatible option if your system calls for it. Just make sure you're working within the general-purpose low and medium pressure range this fitting is built for.

Answer by: Customer Support on Jun 25, 2025, 2:40 PM
