Global TTC 1 & 2 Wire Braid Steel Crimp Fitting, M14 x 1.5 Female German DIN 3902 24 deg Flare Light Duty Swivel, -04 Hose, 90 deg Elbow

Application General purpose low and medium pressure hydraulics. Use H277 or H435 where shock hazards exist	D 28.50	Drop Dimension 1.22	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Gender 1 13553	End Size 1 0.38	End Size 2 0.25	End Type 1 Metric	End Type 2 Line/Hose/Tube	H 3.5 mm	Hose Size -04	Mandrel Required No	Supplier Part Number 1A6DLB4	Thread 1 M14 x 1.5	Thread Sealant No	Torque Rating 19-23 LB/FT	Torque Rating 19-23 LB/FT	Alternate Part Numbers Alternate Part Number C1AN79, Alternate Part Number MI-03065198, Alternate Part Number MINO-00015J51549	Tube O.D. 8	Product Weight 0.12 lbs

Product Questions & Answers 1

Product Questions & Answers

trying to swap out a bent fitting i’ve got, is this one the 90 degree elbow with the m14 x 1.5 female din 24 degree flare swivel for a -04 hose

Question by: Phil R on Jul 25, 2025, 3:49 PM

It matches an M14 x 1.5 female German DIN 3902 24 degree flare light duty swivel on a 90 degree elbow, and it’s called out as compatible with -04 hose size. It also lists an 8 mm tube O.D. on the tube side.

Answer by: Customer Support on Jul 27, 2025, 1:35 PM

Similar Products

Model Number	Thread 1	Tube O.D.	Hose Size	D	H
1A10DLB6	M18 x 1.5	12	-06	35	39 mm
1A12DLB8	M22 x 1.5	15	-08	42.3	43 mm
1A16DLB10	M26 x 1.5	18	-10	53.5	59 mm
1A20DLB12	M30 x 2	22	-12	64.8	54 mm
1A25DLB16	M36 x 2	28	-16	120	71 mm
1A5DLB4	M12 x 1.5	6	-04	26.5	26.5 mm
1A6DLB4	M14 x 1.5	8	-04	28.5	3.5 mm
1A8DLB6	M16 x 1.5	10	-06	32	35.5 mm
