AQP REFRIG HOSE

Abrasion Resistance 29	Alternate Part Numbers Alternate Part Number GH001-6RL	Application Air conditioning and refrigeration, Construction, Agriculture and Truck.	Certifications SAE J2064 Type E, Class 2	Color Black	Conductivity 30	Construction 1 Ply Braid	Cover Material EPDM	Dash Size -6	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Effusion Rate R1234yf Effusion: <1kg/m2/yr at 80°C; R134a Effusion: <1.5kg/m2/yr at 80°C	Features Deliver performance and maximum uptime\|Hoses exceed SAE J2064\|Compatible with multiple refrigerants	ICC Hoses and Flexible Tubes	Impulse Cycle Life 150000 cycle	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 2	Minimum Bend Radius 2	Minimum Working Temperature -40	Product Width 0.60	Qualified Hose Fittings EZ Clip or Factory crimp	Reinforcement Material Fabric	Sub Brand None	Supplier Part Number GH001-6RL	Tube Material Polyamide	Product Weight 0.33 lbs

Product Questions & Answers 1

Product Questions & Answers

Does this hose work with R1234yf or is it only rated for the older R134a refrigerant?

Question by: Joyce M on Jun 2, 2025, 9:22 AM

Both refrigerants are covered. The effusion rate for R1234yf runs under 1 kg per square meter per year at 80 degrees C, and R134a comes in under 1.5 kg per square meter per year at the same temperature. It meets SAE J2064 Type E, Class 2 certification, so it holds up to current standards for either refrigerant in A/C and refrigeration work across construction, agriculture, and truck applications.

Answer by: Customer Support on Jun 4, 2025, 6:24 AM
