Polyurethane U-Seals Test-0615

Deep Type	Height is greater than cross section.
Materials	Urethane.
Pressure Range	0 to 6,000 PSI.
Standard Type	Height & cross section are equal.
Temperature Range	-65°F to 220°F
Type B	Height is greater than cross section. Beveled lip design provides superior film breaking.
Type SQB	Height & cross section are equal. Beveled lip design provides superior film breaking.

Products

Model Number	Cross Section	I.D.	O.D.	H
U12-0.62-25B	0.125 in	0.625 in	0.875 in	0.25 in
U12-1.00-25B	0.125 in	1 in	1.25 in	0.25 in
U12-1.25-SQB	0.125 in	1.25 in	1.5 in	0.125 in
U18-1.25-SQB	0.1875 in	1.25 in	1.625 in	0.1875 in
U18-1.75-37B	0.1875 in	1.75 in	2.125 in	0.375 in
U18-2.12-SQB	0.1875 in	2.125 in	2.5 in	0.1875 in
U18-2.50-31B	0.1875 in	2.5 in	2.875 in	0.3125 in
U25-1.25-37B	0.25 in	1.25 in	1.75 in	0.375 in
U25-1.50-37B	0.25 in	1.5 in	2 in	0.375 in
U25-2.00-37B	0.25 in	2 in	2.5 in	0.375 in
U25-2.50-37B	0.25 in	2.5 in	3 in	0.375 in
U25-3.00	0.25 in	3 in	3.5 in	0.25 in
U25-3.00-37B	0.25 in	3 in	3.5 in	0.375 in
U25-3.50-37B	0.25 in	3.5 in	4 in	0.375 in
U25-4.00-SQB	0.25 in	4 in	4.5 in	0.25 in
U25-4.50	0.25 in	4.5 in	5 in	0.25 in
U25-5.00	0.25 in	5 in	5.5 in	0.25 in
U12-0.18-25B	0.125 in	0.1875 in	0.438 in	0.25 in
U12-0.25-25B	0.125 in	0.25 in	0.5 in	0.25 in
U12-0.25-SQB	0.125 in	0.25 in	0.5 in	0.125 in
U12-0.31-25B	0.125 in	0.3125 in	0.563 in	0.25 in
U12-0.31-SQB	0.125 in	0.3125 in	0.563 in	0.125 in
U12-0.37	0.125 in	0.375 in	0.625 in	0.125 in
U12-0.50-25B	0.125 in	0.5 in	0.75 in	0.25 in
U12-0.50-SQB	0.125 in	0.5 in	0.75 in	0.125 in
U12-0.56	0.125 in	0.625 in	0.938 in	0.125 in
U12-0.62-SQB	0.125 in	0.625 in	0.875 in	0.125 in
U12-0.68	0.125 in	0.6875 in	0.938 in	0.125 in
U12-0.75-18B	0.125 in	0.75 in	1 in	0.1875 in
U12-0.75-25B	0.125 in	0.75 in	1 in	0.25 in
U12-0.75-SQB	0.125 in	0.75 in	1 in	0.125 in
U12-0.81	0.125 in	0.8125 in	1.063 in	0.125 in
U12-0.87-25B	0.125 in	0.875 in	1.125 in	0.25 in
U12-0.87-SQB	0.125 in	0.875 in	1.125 in	0.125 in
U12-1.00-18B	0.125 in	1 in	1.25 in	0.1875 in
U12-1.00-SQB	0.125 in	1 in	1.25 in	0.125 in
U12-1.06-SQB	0.125 in	1.0625 in	1.313 in	0.125 in
U12-1.12-25B	0.125 in	1.0625 in	1.375 in	0.25 in
U12-1.12-SQB	0.125 in	1.0625 in	1.375 in	0.125 in
U12-1.18	0.125 in	0.188 in	1.438 in	0.125 in
U12-1.18-18B	0.125 in	0.188 in	1.438 in	0.1875 in
U12-1.18-25B	0.125 in	0.188 in	1.438 in	0.25 in
U12-1.25-18B	0.125 in	1.25 in	1.5 in	0.1875 in
U12-1.25-25B	0.125 in	1.25 in	1.5 in	0.25 in
U12-1.37-25B	0.125 in	1.375 in	1.625 in	0.25 in
U12-1.37-SQB	0.125 in	1.375 in	1.625 in	0.125 in
U12-1.50-25B	0.125 in	1.5 in	1.75 in	0.25 in
U12-1.50-SQB	0.125 in	1.5 in	1.75 in	0.125 in
U12-1.62-SQB	0.125 in	1.625 in	1.875 in	0.125 in
U12-1.75-SQB	0.125 in	1.75 in	2 in	0.125 in
U12-2.00	0.125 in	2 in	2.25 in	0.125 in
U12-2.25	0.125 in	2.25 in	2.5 in	0.125 in
U12-2.75	0.125 in	2.75 in	3 in	0.125 in
U15-1.18	0.1563 in	0.188 in	1.5 in	0.1563 in
U15-1.25	0.1563 in	1.25 in	1.563 in	0.1563 in
U15-1.37	0.1563 in	1.375 in	1.688 in	0.1563 in
U18-0.50	0.1875 in	0.5 in	0.875 in	0.1875 in
U18-0.62-31B	0.1875 in	0.625 in	1 in	0.3125 in
U18-0.62-SQB	0.1875 in	0.625 in	1 in	0.1875 in
U18-0.75-31B	0.1875 in	0.75 in	1.125 in	0.3125 in
U18-0.75-SQB	0.1875 in	0.75 in	1.125 in	0.1875 in
U18-0.87-31B	0.1875 in	0.875 in	1.25 in	0.3125 in
U18-0.87-SQB	0.1875 in	0.875 in	1.25 in	0.1875 in
U18-1.00-25B	0.1875 in	1 in	1.375 in	0.25 in
U18-1.00-31B	0.1875 in	1 in	1.375 in	0.3125 in
U18-1.00-37B	0.1875 in	1 in	1.375 in	0.375 in
U18-1.00-SQB	0.1875 in	1 in	1.375 in	0.1875 in
U18-1.12-25B	0.1875 in	1.0625 in	1.5 in	0.25 in
U18-1.12-31B	0.1875 in	1.0625 in	1.5 in	0.3125 in
U18-1.12-SQB	0.1875 in	1.0625 in	1.5 in	0.1875 in
U18-1.18	0.1875 in	0.188 in	1.563 in	0.1875 in
U18-1.25-25B	0.1875 in	1.25 in	1.625 in	0.25 in
U18-1.25-31B	0.1875 in	1.25 in	1.625 in	0.3125 in
U18-1.25-37B	0.1875 in	1.25 in	1.625 in	0.375 in
U18-1.37-25B	0.1875 in	1.375 in	1.75 in	0.25 in
U18-1.37-31B	0.1875 in	1.375 in	1.75 in	0.3125 in
U18-1.37-37B	0.1875 in	1.375 in	1.75 in	0.375 in
U18-1.37-SQB	0.1875 in	1.375 in	1.75 in	0.1875 in
U18-1.50-25B	0.1875 in	1.5 in	1.875 in	0.25 in
U18-1.50-31B	0.1875 in	1.5 in	1.875 in	0.3125 in
U18-1.50-37B	0.1875 in	1.5 in	1.875 in	0.375 in
U18-1.50-SQB	0.1875 in	1.5 in	1.875 in	0.1875 in
U18-1.62	0.1875 in	1.625 in	2 in	0.1875 in
U18-1.62-25B	0.1875 in	1.625 in	2 in	0.25 in
U18-1.62-31B	0.1875 in	1.625 in	2 in	0.3125 in
U18-1.62-37B	0.1875 in	1.625 in	2 in	0.375 in
U18-1.62-SQB	0.1875 in	1.625 in	2 in	0.1875 in
U18-1.75-25B	0.1875 in	1.75 in	2.125 in	0.25 in
U18-1.75-31B	0.1875 in	1.75 in	2.125 in	0.3125 in
U18-1.75-SQB	0.1875 in	1.75 in	2.125 in	0.1875 in
U18-1.87-37B	0.1875 in	1.875 in	2.25 in	0.375 in
U18-1.87-SQB	0.1875 in	1.875 in	2.25 in	0.1875 in
U18-2.00-31B	0.1875 in	2 in	2.375 in	0.3125 in
U18-2.00-37B	0.1875 in	2 in	2.375 in	0.375 in
U18-2.00-SQB	0.1875 in	2 in	2.375 in	0.1875 in
U18-2.12-25B	0.1875 in	2.125 in	2.5 in	0.25 in
U18-2.25-37B	0.1875 in	2.25 in	2.625 in	0.375 in
U18-2.25-SQB	0.1875 in	2.25 in	2.625 in	0.1875 in
U18-2.37-SQB	0.1875 in	2.375 in	2.75 in	0.1875 in
U18-2.50-25B	0.1875 in	2.5 in	2.875 in	0.25 in
U18-2.50-37B	0.1875 in	2.5 in	2.875 in	0.375 in
U18-2.50-SQB	0.1875 in	2.5 in	2.875 in	0.1875 in
U18-2.62-37B	0.1875 in	2.625 in	3 in	0.375 in
U18-2.62-SQB	0.1875 in	2.625 in	3 in	0.1875 in
U18-2.75-37B	0.1875 in	2.75 in	3.125 in	0.375 in
U18-2.75-SQB	0.1875 in	2.75 in	3.125 in	0.1875 in
U18-2.87	0.1875 in	2.875 in	3.25 in	0.1875 in
U18-3.00	0.1875 in	3 in	3.375 in	0.1875 in
U18-3.00-37B	0.1875 in	3 in	3.375 in	0.375 in
U18-3.12-37B	0.1875 in	3.125 in	3.5 in	0.375 in
U18-3.12-SQB	0.1875 in	3.125 in	3.5 in	0.1875 in
U18-3.50-37B	0.1875 in	3.5 in	3.875 in	0.375 in
U18-3.62-37B	0.1875 in	3.625 in	4 in	0.375 in
U18-3.62-SQB	0.1875 in	3.625 in	4 in	0.1875 in
U18-4.00-37B	0.1875 in	4 in	4.375 in	0.375 in
U25-0.75	0.25 in	0.75 in	1.25 in	0.25 in
U25-0.93	0.25 in	0.8125 in	1.438 in	0.25 in
U25-1.00-37B	0.25 in	1 in	1.5 in	0.375 in
U25-1.00-SQB	0.25 in	1 in	1.5 in	0.25 in
U25-1.12	0.25 in	1.0625 in	1.625 in	0.25 in
U25-1.12-37B	0.25 in	1.0625 in	1.625 in	0.375 in
U25-1.18	0.25 in	0.188 in	1.688 in	0.25 in
U25-1.25-SQB	0.25 in	1.25 in	1.75 in	0.25 in
U25-1.37	0.25 in	1.375 in	1.875 in	0.25 in
U25-1.37-37B	0.25 in	1.375 in	1.875 in	0.375 in
U25-1.50-31B	0.25 in	1.5 in	2 in	0.3125 in
U25-1.50-SQB	0.25 in	1.5 in	2 in	0.25 in
U25-1.75	0.25 in	1.75 in	2.25 in	0.25 in
U25-1.75-37B	0.25 in	1.75 in	2.25 in	0.375 in
U25-1.87-37B	0.25 in	1.875 in	2.375 in	0.375 in
U25-2.00-31B	0.25 in	2 in	2.5 in	0.3125 in
U25-2.00-SQB	0.25 in	2 in	2.5 in	0.25 in
U25-2.12-37B	0.25 in	2.125 in	2.625 in	0.375 in
U25-2.25	0.25 in	2.25 in	2.75 in	0.25 in
U25-2.25-37B	0.25 in	2.25 in	2.75 in	0.375 in
U25-2.37-37B	0.25 in	2.375 in	2.875 in	0.375 in
U25-2.50-SQB	0.25 in	2.5 in	3 in	0.25 in
U25-2.62-37B	0.25 in	2.625 in	3.125 in	0.375 in
U25-2.75-37B	0.25 in	2.75 in	3.25 in	0.375 in
U25-2.75-SQB	0.25 in	2.75 in	3.25 in	0.25 in
U25-3.25-37B	0.25 in	3.25 in	3.75 in	0.375 in
U25-3.50	0.25 in	3.5 in	4 in	0.25 in
U25-3.50-SQB	0.25 in	3.5 in	4 in	0.25 in
U25-3.75-37B	0.25 in	3.75 in	4.25 in	0.375 in
U25-3.75-SQB	0.25 in	3.75 in	4.25 in	0.25 in
U25-4.00-37B	0.25 in	4 in	4.5 in	0.375 in
U25-4.00-50D	0.25 in	4 in	4.5 in	0.5 in
U25-4.00-56B	0.25 in	4 in	4.5 in	0.5625 in
U25-4.50-37B	0.25 in	4.5 in	5 in	0.375 in
U25-4.50-56B	0.25 in	4.5 in	5 in	0.5625 in
U25-4.50-62B	0.25 in	4.5 in	5 in	0.625 in
U25-5.00-37B	0.25 in	5 in	5.5 in	0.375 in
U25-5.50	0.25 in	5.5 in	6 in	0.25 in
U25-5.50-37B	0.25 in	5.5 in	6 in	0.375 in
U25-5.50-56B	0.25 in	5.5 in	6 in	0.5625 in
U31-1.00-50B	0.3125 in	1 in	1.625 in	0.5 in
U31-1.25	0.3125 in	1.25 in	1.875 in	0.3125 in
U31-1.25-37B	0.3125 in	1.25 in	1.875 in	0.375 in
U31-1.37-37B	0.3125 in	1.375 in	2 in	0.375 in
U31-1.37-SQB	0.3125 in	1.375 in	2 in	0.3125 in
U31-1.50	0.3125 in	1.5 in	2.125 in	0.3125 in
U31-1.75-37B	0.3125 in	1.75 in	2.375 in	0.375 in
U31-1.87	0.3125 in	1.875 in	2.5 in	0.3125 in
U31-2.00	0.3125 in	2 in	2.625 in	0.3125 in
U31-2.00-50B	0.3125 in	2 in	2.625 in	0.5 in
U31-2.25-50B	0.3125 in	2.25 in	2.875 in	0.5 in
U31-2.37	0.3125 in	2.375 in	3 in	0.3125 in
U31-2.50	0.3125 in	2.5 in	3.125 in	0.3125 in
U31-2.50-50B	0.3125 in	2.5 in	3.125 in	0.5 in
U31-2.75	0.3125 in	2.75 in	3.375 in	0.3125 in
U31-2.75-50B	0.3125 in	2.75 in	3.375 in	0.5 in
U31-2.87	0.3125 in	2.875 in	3.5 in	0.3125 in
U31-3.00-50B	0.3125 in	3 in	3.625 in	0.5 in
U31-3.37-50B	0.3125 in	3.375 in	4 in	0.5 in
U31-4.00	0.3125 in	4 in	4.625 in	0.3125 in
U31-4.00-56B	0.3125 in	4 in	4.625 in	0.5625 in
U31-4.37	0.3125 in	4.375 in	5 in	0.3125 in
U31-4.50	0.3125 in	4.5 in	5.125 in	0.3125 in
U37-1.25	0.375 in	1.25 in	2 in	0.375 in
U37-1.75	0.375 in	1.75 in	2.5 in	0.375 in
U37-2.50-50B	0.375 in	2.5 in	3.25 in	0.5 in
U37-2.75	0.375 in	2.75 in	3.5 in	0.375 in
U37-3.25-50B	0.375 in	3.25 in	4 in	0.5 in
U37-3.50	0.375 in	3.5 in	4.25 in	0.375 in
U37-3.75-50D	0.375 in	3.75 in	4.5 in	0.5 in
U37-4.00-62B	0.375 in	4 in	4.75 in	0.625 in
U37-4.25-50D	0.375 in	4.25 in	5 in	0.5 in
U37-4.25-62B	0.375 in	4.25 in	5 in	0.625 in
U37-4.25-SQB	0.375 in	4.25 in	5 in	0.375 in
U37-4.50-62B	0.375 in	4.5 in	5.25 in	0.625 in
U37-5.00-62B	0.375 in	5 in	5.75 in	0.625 in
U37-5.25	0.375 in	5.25 in	6 in	0.375 in
U37-5.25-50D	0.375 in	5.25 in	6 in	0.5 in
U37-6.25-50D	0.375 in	6.25 in	7 in	0.5 in
U50-2.00-SQB	0.5 in	2 in	3 in	0.5 in
U50-2.50	0.5 in	2.5 in	3.5 in	0.5 in
