SALAMI VD6A-P01A-PRA.PRB-NLA-C2/S PARALL

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Key (1)	Supplier Part Number S23480070	Alternate Part Numbers Alternate Part Number C1MV20	Product Weight 5.00 lbs

Product Questions & Answers 2

Product Questions & Answers

What's the max pressure this valve can take, and does that hold across all the main ports?

Question by: Rick Y on Jul 19, 2025, 4:04 PM

Ports P, A, and B are all rated to 5100 PSI, so you're covered consistently across your main working ports. The one exception worth knowing is the outlet port T, which has a max back pressure of 363 PSI. Keep that in mind when you're sizing your return line.

Answer by: Customer Support on Jul 20, 2025, 8:02 PM

got a hydraulic setup that sees some cold mornings and then runs pretty warm later on. what temp range will this VD6A section tolerate?

Question by: Cody B on Feb 15, 2026, 5:01 PM

On the oil side, it is rated for fluid temperatures from -4°F up to 185°F when using standard NBR seals. For the surrounding environment, the ambient range is -22°F to 140°F.

Answer by: Customer Support on Feb 17, 2026, 8:31 AM

Similar Products

Model Number	Key	Product Description
323411302	(2)	SALAMI VDM6/VD6 02A M SPOOL.
R23400322	(3)	SALAMI CO FRICTION KIT.
420192000	A side actuator	SALAMI LEVER STICK KNOB AND KNOB KIT.
796332555	B side actuator	SALAMI VDM6/VD6 E9 45W 12V.
R23400060	(4)	SALAMI LEVER STICK POSITIONING KIT. PR.
R23400210	Spool	SALAMI VDM6/VD6 SPOOL SEAL KIT.
R23400320	(3)	SALAMI R2 DETENT KIT.
R23400321	B side actuator	SALAMI VDM6/VD6A R9 DETENT KIT.
S23480070	(1)	SALAMI VD6A-P01A-PRA.PRB-NLA-C2/S PARALL.
S23480550	(1)	SALAMI VD6A-P02A-PRA.PRB-NLA-C2/S PARALL.
