SALAMI VD12A-P01A-PRA.PRB-MLA-C2/S PARAL

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Supplier Part Number S22480410	Alternate Part Numbers Alternate Part Number C1MV16, Alternate Part Number MI-02665670, Alternate Part Number MINO-00770X20175	Product Weight 14.00 lbs

Product Questions & Answers 2

Product Questions & Answers

Running a high-flow directional control setup on some heavy equipment and need to know if this section can keep up. What's the actual flow capacity on this thing?

Question by: Danny M on Aug 27, 2025, 8:32 AM

Rated at 48 GPM, so it holds up well in high-demand applications. Pressure-wise, the inlet port handles up to 4,000 PSI, and the work ports A and B are rated even higher at 4,500 PSI. That combination makes it a solid fit for heavy mobile or industrial hydraulic circuits where you need both volume and pressure handled reliably in the same section.

Answer by: Customer Support on Aug 28, 2025, 9:08 PM

What kind of oil should I be running in this thing, and how thick can it be?

Question by: Earl B on Dec 3, 2025, 3:34 PM

Optimal performance from this Salami VD12A section calls for mineral oil with a viscosity between 12 and 75 cSt. It can handle viscosity as low as 10 cSt or as high as 460 cSt if needed.

Answer by: Customer Support on Dec 5, 2025, 7:43 AM
