SystemStak Check Valve, NFPA-D03 Size, Check in P, Free Flow towards Work Port, 36.0 PSI Cracking Pressure

Cracking Pressure (psi) 36.00	Brand Danfoss (Power Solutions II LLC)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Function Check in P, Free Flow towards Work Port	Key A	Supplier Part Number 02-138605	Alternate Part Numbers Alternate Part Number C1JL49, Alternate Part Number DGMDC3YPM41	Product Weight 2.08 lbs

Product Questions & Answers 3

Product Questions & Answers

Got a DGMDC-3-Y-PM-41 going on a manifold block. what kind of bolts do we need and how tight should they be?

Question by: Randy O on Dec 20, 2025, 11:42 AM

Fasten these units using 10-24 grade 8 socket head cap screws. You will want to lubricate the threads and torque them down to somewhere between 63 and 80 inch pounds for proper seating.

Answer by: Customer Support on Dec 22, 2025, 6:51 AM

Trying to swap out a stack valve, is this one the D03 SystemStak check in P with free flow toward the work port, and is it the 41 design?

Question by: Frank W on May 9, 2025, 8:51 AM

For replacement matching, the identifiers on this valve are DGMDC-3-Y-PM-41 (41 design) and catalog number C1JL49. Function-wise it is a check in P with free flow toward the work port, and it is an NFPA-D03 size SystemStak style valve.

Answer by: Customer Support on May 11, 2025, 7:23 AM

i’m trying to stop oil from sneakin back the wrong way. which direction does this D03 SystemStak check valve let flow go?

Question by: Rusty C on Mar 4, 2026, 2:16 PM

Function-wise, it allows free flow toward the work port when the check is in the P line, and it blocks flow in the opposite direction.

Answer by: Customer Support on Mar 6, 2026, 8:55 AM

Similar Products

Part Number	Model Number	Key	Function	Cracking Pressure (psi)	Price	Buy Now
02-138605	DGMDC-3-Y-PM-41	A	Check in P, Free Flow towards Work Port	36.0
