main product photo

SV9-10 Series 4-Way, 3-Position Solenoid Cartridge Valve, P Blocked, A&B Open to Tank, Housing: None, Coil: Not Included

Ask A Question
Application
Harvesters, refuse haulers, mobile and industrial applications
Check Valve
No
Circuit Type
P Blocked, A&B Open to Tank
Coil
Not Included
Diode
No
Brand
Danfoss – Hydraulics
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
Features
350 bar (5000 psi) & 227 L/min (60 USgpm)|Reliable, economical and compact|Hardened and ground steel
Housing
None
Installation Type
Screw-in Cartridge
Leakage
Standard
Manual Override Option
No
Number of Housing Ports
4
Number of Valve Ports
4
Operation
Direct Acting
Port Type
Cartrige Only
Recommended Filtration Level
18/16/13 microns
Seal Material
Buna-N
Seal Type
Buna-N
Special Features
None
Style
4-Way 3-Position
Supplier Part Number
02-199329
Switch Connector
No
Valve Material
Cartridge only
Product Weight
2.10 lbs
Alternate Part Numbers
Alternate Part Number C1KX60, Alternate Part Number SV910NF00000000000000A
Product Questions & Answers 5

Product Questions & Answers

got a C-10-4 cavity block already, will this SV9-10 screw right in or am i missing something
Question by: Lynn M on Sep 3, 2025, 5:44 PM
It is a screw-in cartridge built for the C-10-4 cavity, but it ships as cartridge only. You will still need the matching SV9-10 housing (sold separately) and a J Series 20 watt coil (also sold separately) to make a complete working assembly.
Answer by: Customer Support on Sep 5, 2025, 7:24 AM
hey what all comes in the box with this valve do I need to buy a coil and housing or are they included
Question by: Donna P on Aug 19, 2025, 8:38 AM
You will need to purchase the coil and housing separately since this is just the bare cartridge. It requires a J Series 20 Watt coil and fits directly into a C-10-4 size cavity.
Answer by: Customer Support on Aug 20, 2025, 12:38 PM
Does this cartridge come with a housing or do I need to order that separate? Also what about the coil, is that thrown in?
Question by: Sherry E on Jun 10, 2025, 8:07 PM
Neither the housing nor the coil are included with this cartridge. The cavity size you'll need is C-10-4, and that has to be ordered separately. Same goes for the coil, the J Series 20 Watt coil is a common match but it's a separate purchase. Worth getting both sorted out before you go to install so everything's on hand at once.
Answer by: Customer Support on Jun 11, 2025, 8:31 PM
got a manifold already, does this valve come with the coil and housing or is it just the cartridge?
Question by: Lyle R on Mar 28, 2025, 5:56 PM
Cartridge only is what you are getting here. It does not include a coil, and it does not include a housing. It installs as a screw in cartridge and needs a machined C-10-4 cavity or a separate housing.
Answer by: Customer Support on Mar 30, 2025, 10:09 AM
Will this valve hold up okay in a hydraulic system on a farm combine? We get some pretty hot summers around here.
Question by: Jimmy A on Jul 2, 2025, 10:20 AM
This SV9-10 series valve is rated for temperatures between -40°F and 248°F, so it should handle even a hot summer without issue.
Answer by: Customer Support on Jul 4, 2025, 7:05 AM
