SV9-10 Series 4-Way, 3-Position Solenoid Cartridge Valve, Tandem Center, Housing: None, Coil: Not Included

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Circuit Type Tandem Center	Coil Not Included	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Leakage Standard	Manual Override Option No	Number of Housing Ports 4	Number of Valve Ports 4	Operation Direct Acting	Port Type Cartrige Only	Recommended Filtration Level 18/16/13 microns	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style 4-Way 3-Position	Supplier Part Number 02-199325	Switch Connector No	Valve Material Cartridge only	Product Weight 0.52 lbs	Alternate Part Numbers Alternate Part Number 565549, Alternate Part Number C1BT30, Alternate Part Number C1KY86, Alternate Part Number DSSV910A000, Alternate Part Number SV910A000, Alternate Part Number SV910NA00000000000000A

Product Questions & Answers 3

Product Questions & Answers

does this valve come with the coil or housing, or do i need to track those down separate?

Question by: Hugh H on May 16, 2025, 8:43 AM

The cartridge itself is what you get here. No coil and no housing are included. You'll need a J Series 20 Watt coil and a separate housing with a C-10-4 cavity size, both sold separately. Worth making sure you've got those lined up before installation since the cartridge won't function without them.

Answer by: Customer Support on May 17, 2025, 7:17 PM

What kind of machines would use this valve?

Question by: Floyd T on Apr 24, 2025, 7:55 AM

Application-wise, this valve is often found in mobile and industrial hydraulic systems, like the ones used in harvesters and refuse haulers.

Answer by: Customer Support on Apr 26, 2025, 8:28 AM

got a tandem center setup here, when neither coil is powered what’s this valve doing with the ports?

Question by: Shane M on Mar 8, 2026, 11:00 AM

In the de-energized position on the tandem center version, it lets flow go from port 3 to port 1 and it blocks ports 2 and 4. When you energize solenoid 1, it routes 3 to 2 and 4 to 1. When you energize solenoid 2, it routes 3 to 4 and 2 to 1.

Answer by: Customer Support on Mar 10, 2026, 10:14 AM

Similar Products

Part Number	Model Number	Circuit Type	Housing	Coil	Seal Material	Price	Buy Now
02-199329	SV910NF00000000000000A	P Blocked, A&B Open to Tank	None	Not Included	Buna-N
02-199325	SV910NA00000000000000A	Tandem Center	None	Not Included	Buna-N
