SV5-8-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil Not Included	Coil Series 8 series, 20 W	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Manual Override Option No	Number of Housing Ports 2	Number of Valve Ports 2	Port Type Cartrige Only	Recommended Filtration Level 18/16/13	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style 2-Way 2-Position Normally Closed	Supplier Part Number 02-160759	Switch Connector No	Valve Material Cartridge only	Voltage volt	Product Weight 0.22 lbs	Alternate Part Numbers Alternate Part Number C1ZZ82, Alternate Part Number SV58C000

Product Questions & Answers 4

Product Questions & Answers

how tight is the seal on this valve when its closed up? worried about leakby on a mobile setup

Question by: Duane E on Feb 25, 2026, 12:03 PM

At 3000 PSI you are looking at a maximum internal leakage of less than 5 drops per minute. It uses standard Buna-N seals to keep things restricted when in the de-energized position blocking flow from port 2 to 1.

Answer by: Customer Support on Feb 27, 2026, 6:56 AM

does this valve come with the coil and housing, or is that all bought separate?

Question by: Judy H on Oct 17, 2025, 8:58 PM

The cartridge itself is what you get here. No coil, no housing included. Both are sold separately, and the valve requires a machined cavity sized C-8-2 for installation. Worth making sure you have that cavity ready before ordering, or picking up the matching housing at the same time.

Answer by: Customer Support on Oct 19, 2025, 2:21 PM

putting this on a little harvester manifold, what all do i need besides the cartridge itself?

Question by: Tammy B on Dec 6, 2025, 6:48 PM

For installation you will need a machined cavity or housing in the C-8-2 cavity size, since the valve is a screw-in cartridge and the housing is not included. You will also need a compatible coil because this part ships without a coil.

Answer by: Customer Support on Dec 8, 2025, 6:40 PM

Will this valve work on a harvester?

Question by: Wayne P on Jan 6, 2026, 6:59 AM

Yes, this Danfoss SV5-8-C series cartridge valve is suitable for use in harvesters, refuse haulers, and other mobile and industrial applications.

Answer by: Customer Support on Jan 8, 2026, 6:53 AM

Similar Products

Part Number	Model Number	Manual Override Option	Housing	Coil	Seal Material	Price	Buy Now
02-160759	SV5-8-C-0-00		None	Not Included	Buna-N
