main product photo

SV4B-12-3 Series 3-Way, 2-Position, Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Ask A Question
Application
Harvesters, refuse haulers, mobile and industrial applications
Check Valve
No
Coil
Not Included
Diode
No
Brand
Danfoss – Hydraulics
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
Features
350 bar (5000 psi) & 227 L/min (60 USgpm)|Reliable, economical and compact|Hardened and ground steel
Housing
None
Manual Override Option
No
Seal Material
Buna-N
Special Features
None
Style
3-Way 2-Position
Supplier Part Number
02-200192
Switch Connector
No
Product Weight
0.93 lbs
Alternate Part Numbers
Alternate Part Number C1MG20
Product Questions & Answers 3

Product Questions & Answers

so with it sittin there de-energized, which ports are actually open and which one’s blocked?
Question by: Ralph A on Feb 23, 2026, 11:54 AM
In the de-energized position, flow goes from port 1 to port 2 and port 3 is blocked. When you energize the solenoid, it switches so flow goes from port 2 to port 3 and port 1 is blocked.
Answer by: Customer Support on Feb 25, 2026, 11:38 AM
How much hydraulic fluid can this thing handle? I'm runnin' some pretty hefty equipment.
Question by: Pete W on May 21, 2025, 6:05 PM
Flow rating on this valve is up to 11 gallons per minute.
Answer by: Customer Support on May 23, 2025, 6:23 AM
does this valve come with the coil and housing, or do i need to order those separate?
Question by: Norm G on Aug 30, 2025, 8:55 AM
The coil and housing are both sold separately on this one. The cartridge itself is what you're getting here, model SV4B-12-3P-0-00, and it requires a C-12-3 cavity size housing for installation. The coil you'll need is from the R Series. Neither piece ships with the valve, so make sure to add both before you put in your order if you need the complete setup.
Answer by: Customer Support on Aug 31, 2025, 1:46 PM

Similar Products

Part Number Model Number Housing Coil Seal Material Price Buy Now
02-200192 SV4B-12-3P-0-00 None Not Included Buna-N
