SV4-10-3 Series 3-Way, 2-Position Solenoid Cartridge Valve, Housing: None, Coil: 115VAC 1/2" NPT conduit

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil 115VAC 1/2" NPT conduit	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Manual Override Option No	Seal Material Buna-N	Supplier Part Number 02-167839	Switch Connector No	Voltage 115 volt	Product Weight 1.22 lbs	Alternate Part Numbers Alternate Part Number C1KH68, Alternate Part Number HW-859416

Product Questions & Answers 1

Product Questions & Answers

what exactly happens when this valve ain't energized, does it just block everything or is flow still moving somewhere?

Question by: Scott H on Oct 24, 2025, 8:30 PM

Flow stays active between ports 1 and 2 in the de-energized state, while port 3 stays blocked. Once you energize it, that switches over, port 2 routes to port 3 and port 1 gets blocked. It's a full path swap, not a shutoff, so fluid is always moving through one of those two routes depending on whether the solenoid is pulled in or not.

Answer by: Customer Support on Oct 26, 2025, 3:36 PM

Similar Products

Part Number	Model Number	Manual Override Option	Housing	Coil	Seal Material	Price	Buy Now
02-167839	SV4-10-3-0-115AP		None	115VAC 1/2" NPT conduit	Buna-N
566307	SV4-10-3-0-00		None	Not Included	Buna-N
