SV3-12-O Series 2-Way, 2-Position, Normally Open Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil Not Included	Coil Series J series, 23 W	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Manual Override Option No	Number of Housing Ports 2	Number of Valve Ports 2	Port Type Cartrige Only	Recommended Filtration Level 17/15/12	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style 2-Way 2-Position Normally Open	Supplier Part Number 02-161311	Switch Connector No	Valve Material Cartridge only	Product Weight 0.58 lbs	Alternate Part Numbers Alternate Part Number C1FQ44, Alternate Part Number SV3120000

Product Questions & Answers 3

Product Questions & Answers

got a screw-in manifold with a C-12-2 cavity, is this the right cartridge for it or am i barking up the wrong tree

Question by: Peggy B on Dec 2, 2025, 5:18 PM

Fit comes down to the cavity, and this valve is a screw-in cartridge built for a C-12-2 or C-12-2U cavity. Keep in mind it ships as the cartridge only, so the housing is separate.

Answer by: Customer Support on Dec 4, 2025, 6:21 AM

running this on a refuse hauler that sees pretty hard daily use -- does the valve hold up once its energized or does it leak bad over time?

Question by: Hank C on Oct 20, 2025, 6:22 PM

Leakage from port 2 to port 1 is rated at less than 5 drops per minute maximum at 3000 PSI when the valve is energized. That's a tight spec for a valve in this class, and the cartridge body is hardened and ground steel, so it holds up well under the kind of repetitive cycling you'd see on a refuse truck. The Buna-N seals are rated for a temperature range of -40°F to 248°F, so heat buildup during heavy daily runs isn't going to be an immediate concern either.

Answer by: Customer Support on Oct 21, 2025, 9:35 PM

What size cavity does this thing need?

Question by: Pete J on Sep 3, 2025, 6:13 AM

For installation, this cartridge valve requires a cavity size C-12-2 or C-12-2U.

Answer by: Customer Support on Sep 4, 2025, 1:07 PM

Similar Products

Part Number	Model Number	Manual Override Option	Housing	Coil	Seal Material	Price	Buy Now
02-161311	SV3-12-O-0-00		None	Not Included	Buna-N
