SV3-12-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil Not Included	Coil Series J series, 23 W	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Manual Override Option No	Number of Housing Ports 2	Number of Valve Ports 2	Port Type Cartrige Only	Recommended Filtration Level 18/16/13	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style 2-Way 2-Position Normally Closed	Supplier Part Number 02-161062	Switch Connector No	Valve Material Cartridge only	Product Weight 0.51 lbs	Alternate Part Numbers Alternate Part Number C1FQ33, Alternate Part Number SV312C000

Product Questions & Answers 4

Product Questions & Answers

so with it sittin there de-energized, which way is blocked and which way is free flow?

Question by: Lance S on May 15, 2025, 7:43 PM

In the de-energized state it blocks flow from port 2 to port 1, and it allows free flow from port 1 to port 2. When you energize the solenoid, it opens up for flow in both directions.

Answer by: Customer Support on May 17, 2025, 2:51 PM

trying to figure out what coil goes on this valve. does it come in the box or do i gotta buy it separate

Question by: Vince R on May 5, 2025, 3:06 PM

Buying the bare cartridge means you need to get the coil and housing separately. The correct coil for this unit is a J series 23-watt model. If you lack an existing manifold, look for a housing with a C-12-2 or C-12-2U cavity size.

Answer by: Customer Support on May 7, 2025, 6:47 AM

valve blocks flow one way when it ain't powered up, right? trying to figure out if this'll work for a load holding setup on a harvester

Question by: Bonnie M on Aug 14, 2025, 8:03 AM

Correct on the flow behavior. When the solenoid is off, flow from port 2 to port 1 is blocked, but fluid can still move freely from port 1 to port 2. Once you energize it, the pilot poppet lifts off the seat and the valve opens in both directions. Low leakage applications like load holding are exactly what this was built for, and it sees regular use on harvesters and similar mobile equipment for that reason. Just keep in mind the coil and housing are both sold separately, so you'll need to source those alongside the cartridge.

Answer by: Customer Support on Aug 15, 2025, 9:22 AM

reckon this valve will hold up on my harvester? We run that thing pretty hard.

Question by: Wes F on Jan 8, 2026, 1:43 PM

Designed for both mobile and industrial applications, this Vickers/Eaton solenoid valve is built to handle high-pressure jobs, up to 5000 psi. It should be a solid choice for your harvester, assuming it meets the other spec requirements.

Answer by: Customer Support on Jan 10, 2026, 10:09 AM
