SV3-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: 12VDC

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil 12VDC	Coil Series 210 bar	Coil Special Features None	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Leakage less than 5 drops/min, max @ 210 bar	Manual Override Option No	Number of Housing Ports 2	Number of Valve Ports 2	Port Type Cartrige Only	Recommended Filtration Level 18/16/13	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style 2-Way 2-Position Normally Closed	Supplier Part Number 565657	Switch Connector No	Valve Material Cartridge only	Voltage 12 volt	Voltage Type 12307	Product Weight 0.92 lbs	Alternate Part Numbers Alternate Part Number C1MZ62, Alternate Part Number SV310C012DG

Product Questions & Answers 2

Product Questions & Answers

Reckon this'll fit in a standard C-10-2 cavity, or am I gonna need somethin' special?

Question by: Brett B on Dec 31, 2025, 8:02 PM

This SV3-10-C series valve is indeed compatible with a C-10-2 cavity housing. Just make sure you get the housing separately since it ain't included.

Answer by: Customer Support on Jan 2, 2026, 6:43 AM

does this valve need a housing included or do i have to buy that separate

Question by: Gene R on Apr 14, 2025, 9:17 AM

The cartridge itself ships without a housing. You'll need to source a C-10-2 cavity housing separately before installation. Same goes for the coil if you don't already have one on hand. Both are sold apart from this unit, so make sure you've got those pieces lined up before you go pulling the old valve out.

Answer by: Customer Support on Apr 15, 2025, 3:18 PM

Similar Products

Part Number	Model Number	Manual Override Option	Housing	Coil	Seal Material	Price	Buy Now
565536	SV3-10-C-0-00		None	Not Included	Buna-N
565657	SV3-10-C-0-12DG		None	12VDC	Buna-N
