SV13-20-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil Not Included	Coil Series 10 series, 29 W	Coil Special Features None	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Leakage Standard	Manual Override Option No	Number of Housing Ports 2	Number of Valve Ports 2	Operation Direct Acting	Port Type Cartrige Only	Recommended Filtration Level 18/16/13	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style 2-Way 2-Position Normally Closed	Supplier Part Number 02-175819	Switch Connector No	Valve Material Cartridge only	Product Weight 1.40 lbs	Alternate Part Numbers Alternate Part Number C1MG15, Alternate Part Number SV1320C000

Product Questions & Answers 3

Product Questions & Answers

Will this here valve work on my wood splitter?

Question by: Lyle M on Dec 15, 2025, 8:49 AM

This Eaton Vickers solenoid valve is suitable for mobile and industrial applications, including harvesters and refuse haulers. It's built to handle high pressures, so it should work in a wood splitter system if the specs line up.

Answer by: Customer Support on Dec 16, 2025, 2:31 PM

got a SV13-20-C-0-00 here, but i dont see a coil with it. is that normal or am i missing something

Question by: Lee C on Sep 5, 2025, 12:02 PM

Coil and housing are not included with this cartridge valve. It is the screw-in cartridge only, and it needs a C-20-2 cavity housing plus a compatible H series coil (10 series, 29 W) to run.

Answer by: Customer Support on Sep 7, 2025, 6:35 AM

valve shows up without a coil or housing, is that normal or did something get left out of my order?

Question by: Dean G on Jan 3, 2026, 10:12 AM

That's how it ships. The cartridge itself is what you're getting here. The C-20-2 cavity housing and the coil are both sold as separate items. You'll need to order those on their own to put together a complete working assembly. The coil series compatible with this one is the H series, and the coil wattage runs 29 watts on the 10 series side. Worth making sure you've got all three pieces lined up before you go to install it.

Answer by: Customer Support on Jan 4, 2026, 1:22 PM

Similar Products

Part Number	Model Number	Housing	Coil	Seal Material	Price	Buy Now
02-175819	SV13-20-C-0-00	None	Not Included	Buna-N
