SV13-16-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil Not Included	Coil Series 10 series, 29 W	Coil Special Features None	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Leakage Standard	Manual Override Option No	Number of Housing Ports 2	Number of Valve Ports 2	Operation Pilot Operated	Port Type Cartrige Only	Recommended Filtration Level 18/16/13	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style 2-Way 2-Position Normally Closed	Supplier Part Number 02-175823	Switch Connector No	Valve Material Cartridge only	Product Weight 0.87 lbs	Alternate Part Numbers Alternate Part Number C1MG17, Alternate Part Number SV1316C000

Product Questions & Answers 3

Product Questions & Answers

runs at 5000 psi all day long on our refuse trucks, but what's the actual flow this thing can handle before it starts causing problems?

Question by: Tammy G on Jul 24, 2025, 4:51 PM

Rated flow tops out at 35 GPM, and the pressure ceiling is 5000 PSI. Those numbers hold for both mobile and industrial setups, so refuse hauler duty is well within range. Keep in mind this is the cartridge only, no coil or housing included, so you'll need to source those separately before it's ready to run.

Answer by: Customer Support on Jul 26, 2025, 4:43 PM

got a spot for a C-16-2 cavity already. does this SV13-16-C just screw in there, or am I missing a housing?

Question by: Stan J on Feb 20, 2026, 11:56 AM

For installation, it uses a C-16-2 machined cavity and it’s a screw-in cartridge style valve. The “Housing: None” note means you are only getting the cartridge, so you still need a proper cavity or housing block that’s machined for C-16-2.

Answer by: Customer Support on Feb 22, 2026, 6:49 AM

Reckon this would work on a refuse truck?

Question by: Cheryl K on Nov 7, 2025, 12:07 PM

Application-wise, yes, this Vickers/Eaton SV13-16-C series valve is listed for use on refuse haulers, along with harvesters and other mobile and industrial applications.

Answer by: Customer Support on Nov 9, 2025, 9:05 AM

Similar Products

Part Number	Model Number	Housing	Coil	Seal Material	Price	Buy Now
02-175823	SV13-16-C-0-00	None	Not Included	Buna-N
