SV13-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil Not Included	Coil Series 10 Series, 29 W	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Manual Override Option No	Number of Housing Ports 2	Number of Valve Ports 2	Port Type Cartrige Only	Recommended Filtration Level 18/16/13	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style 2-Way 2-Position Normally Closed	Supplier Part Number 02-175805	Switch Connector No	Valve Material Cartridge only	Product Weight 0.40 lbs	Alternate Part Numbers Alternate Part Number C1MG12, Alternate Part Number SV1310C000

Product Questions & Answers 1

Product Questions & Answers

trying to hold a load with low leakage, is this the kind of valve for that or is it more of a dump valve deal

Question by: Tommy M on Jun 23, 2025, 12:35 PM

For low leakage load holding, the SV13-10-C is a good fit since it is a poppet style, normally closed, pilot operated 2-way valve with internal leakage listed at 5 drops per minute max at 5000 PSI. It also gets used as a general purpose diverter or dump valve, so it can cover either role depending on how you plumb ports 1 and 2 in your circuit.

Answer by: Customer Support on Jun 24, 2025, 1:45 PM

Similar Products

Part Number	Model Number	Housing	Coil	Seal Material	Price	Buy Now
02-175805	SV13-10-C-0-00	None	Not Included	Buna-N
