SV1-8-3 Series 3-Way, 2-Position, Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil Not Included	Coil Series 8 series, 20 W	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Leakage Standard	Manual Override Option No	Number of Housing Ports 3	Number of Valve Ports 3	Operation Direct Acting	Port Type Cartrige Only	Recommended Filtration Level 18/16/13	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style 3-Way 2-Position	Supplier Part Number 02-160771	Switch Connector No	Valve Material Cartridge only	Voltage volt	Product Weight 0.24 lbs	Alternate Part Numbers Alternate Part Number C1HL36, Alternate Part Number N2BVS018, Alternate Part Number SV183000

Product Questions & Answers 1

Product Questions & Answers

What's actually happening inside this valve when it ain't energized, like which ports are open and which ones are blocked?

Question by: Randy C on Sep 1, 2025, 9:04 AM

When the solenoid is de-energized, flow moves from port 2 to port 1, and port 3 stays blocked. Flip it to energized and the situation reverses, port 1 flows to port 3, and port 2 gets blocked. That makes it well suited for setups like single acting cylinders where you need separate pressure and tank lines routed through the same valve body.

Answer by: Customer Support on Sep 2, 2025, 1:26 PM

Similar Products

Part Number	Model Number	Manual Override Option	Housing	Coil	Seal Material	Price	Buy Now
02-160771	SV1-8-3-0-00		None	Not Included	Buna-N
