Steel Metric Flareless Fitting, 16.00 mm S Series Cap

Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	L 24	Maximum Operating Pressure 630	Series S	Supplier Part Number WAL612341	Tube O.D. 16	Tube O.D. 16	Alternate Part Numbers Alternate Part Number C1LA18	Product Weight 0.08 lbs

Product Questions & Answers 3

Product Questions & Answers

Does this cap work with 16mm tube fittings running at high pressure, like up around 500 or 600 bar?

Question by: Curt P on May 31, 2025, 8:56 AM

Rated up to 630 bar, this cap handles that range without issue. It's built for S Series metric flareless assemblies with a 16mm tube OD, so as long as your system uses that tube size and conforms to DIN standards, you're in the right territory. The 4:1 safety factor is already built into that pressure rating.

Answer by: Customer Support on Jun 2, 2025, 6:42 AM

got a 16mm metric tube fitting setup already, is this cap the right one to close it off

Question by: Harold H on Jun 7, 2025, 7:42 AM

For a 16 mm tube OD metric flareless tube fitting assembly in Series S, this cap is the matching size. It’s the Eaton Aeroquip Waltech part C1LA18, also sold as WAL612341.

Answer by: Customer Support on Jun 8, 2025, 7:50 AM

reckon this cap will hold up if I'm pushin' close to that max pressure rating of 630 bar?

Question by: Steve C on Sep 7, 2025, 4:08 PM

This cap is certainly suited to that level of pressure. The Series S fittings are rated from 160 to 630 bar, with a 4:1 safety factor, so you've got some margin built in.

Answer by: Customer Support on Sep 9, 2025, 3:07 PM

Similar Products

Model Number	Tube O.D.	Series	Maximum Operating Pressure	L
WAL612335	18	L	400	21
WAL612336	22	L	250	23
WAL612330	6	L	800	17
WAL612341	16	S	630	24
WAL612343	25	S	420	31
