Steel Adapter, 1-11/16-12 Male O-Ring Face Seal Cap

A 1.17	Alternate Part Numbers Alternate Part Number C1ZX84, Alternate Part Number MI-00444610, Alternate Part Number MINO-00015I01241	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Gender 1 13553	End Type 1 ORS	Minimum Working Temperature -40	Supplier Part Number FF9863-20S	Thread 2 1-11/16-12	Thread Sealant No	Tube O.D. 1.25	Tube O.D. 1.25	Product Weight 0.58 lbs

Product Questions & Answers 4

Product Questions & Answers

what's the tube OD on this cap, and is that 1-11/16-12 thread the male end or the female side?

Question by: Patty G on May 28, 2025, 7:01 PM

The tube OD on this cap is 1.25 inches. The 1-11/16-12 thread is the male O-ring face seal end, and the cap itself is female, meaning it threads over that male fitting to seal it off. So you've got a male ORS port on your line, and this cap screws onto it to close it up.

Answer by: Customer Support on May 30, 2025, 6:18 AM

i’ve got a 1-11/16-12 ORFS port I need to deadhead for now. Is FF9863-20S the right cap for that?

Question by: Joyce B on Aug 10, 2025, 11:36 AM

For a temporary close-off on an O-Ring Face Seal connection, this part is an ORS cap assembly with a 1-11/16-12 male thread, so it matches that thread callout and style.

Answer by: Customer Support on Aug 12, 2025, 10:26 AM

What size is the O-ring face seal on this cap? I'm trying to match it up to something I already got.

Question by: Rhonda B on Dec 29, 2025, 5:03 PM

This adapter cap has a 1-11/16-12 male O-ring face seal. That should help you find the right match.

Answer by: Customer Support on Dec 30, 2025, 8:34 PM

what thread size is on this cap? need to make sure it'll fit a 1-11/16-12 port before I order

Question by: Chad A on Dec 5, 2025, 9:24 PM

The male fitting on this cap is 1-11/16-12, which is a standard O-Ring Face Seal thread size. It'll seat directly onto a matching female ORS port and create a clean, leak-resistant seal when torqued down properly. Just confirm your port matches that thread pitch and you're good to go.

Answer by: Customer Support on Dec 7, 2025, 6:17 AM

Similar Products

Model Number	Tube O.D.	Thread 2	A
FF9863-04S	0.25	9/16-18	0.66
FF9863-06S	0.38	11/16-16	0.75
FF9863-08S	0.5	13/16-16	0.9
FF9863-10S	0.63	1-14	1
FF9863-12S	0.75	1-3/16-12	1.1
FF9863-16S	1	1-7/16-12	1.17
FF9863-20S	1.25	1-11/16-12	1.17
