Steel Adapter, 13/16-16 Male O-Ring Face Seal Cap

A 0.90	Alternate Part Numbers Alternate Part Number C1CV78, Alternate Part Number MI-00306486, Alternate Part Number MINO-00015F55562	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Gender 1 13553	End Size 1 0.81	End Size 2 0.50	End Type 1 ORS	Minimum Working Temperature -40	Supplier Part Number FF9863-08S	Thread 2 13/16-16	Thread Sealant No	Tube O.D. 0.50	Tube O.D. 0.5	Product Weight 0.12 lbs

Product Questions & Answers 5

Product Questions & Answers

got a half inch tube line that needs capping off on an ORS port, this the right size for that?

Question by: Gary M on Aug 4, 2025, 8:25 AM

For a 1/2 inch ORS tube line, the thread size you need is 13/16-16, and that is exactly what this cap is threaded to. It seats against the flat face of the port using an o-ring seal, so you get a leak-free closure without thread sealant. Straight swap, no tape, no compound needed.

Answer by: Customer Support on Aug 6, 2025, 6:35 AM

trying to cap off a 13/16-16 o-ring face seal port, is this the right one?

Question by: Sherry S on Sep 21, 2025, 9:06 AM

For a 13/16-16 thread on an O-Ring Face Seal connection, this part matches that thread spec and is an ORS cap assembly in the Danfoss FF9863 series.

Answer by: Customer Support on Sep 23, 2025, 6:21 AM

Will this cap fit a standard O-ring face seal port?

Question by: Kent P on Mar 25, 2025, 11:20 AM

This Eaton Aeroquip adapter cap is specifically made to fit a 13/16-16 male O-ring face seal. It's designed to protect those ports from contamination and damage when they aren't in use.

Answer by: Customer Support on Mar 27, 2025, 6:05 AM

got a port that needs capping off on a hydraulic system, this a 13/16-16 ORB or is it the O-ring face seal thread?

Question by: Pete S on Aug 19, 2025, 8:39 PM

The thread on this cap is 13/16-16 O-ring face seal, which is the ORFS standard. That's a flat-face port connection with the seal made by an O-ring sitting against a flat machined surface, not an O-ring seated in an angled boss like ORB fittings use. If your port has a flat face and uses that thread size, this cap will match up correctly.

Answer by: Customer Support on Aug 21, 2025, 5:51 PM

got a port with 13/16-16 ORFS threads. is this the right cap to close it off?

Question by: Sheila K on May 16, 2025, 6:13 AM

For a 13/16-16 male O-Ring Face Seal (ORFS) cap assembly, FF9863-08S is the matching style. It’s a straight adapter ORS cap meant to seal off that ORFS male thread size.

Answer by: Customer Support on May 17, 2025, 3:27 PM

Similar Products

Model Number	Tube O.D.	Thread 2	A
FF9863-04S	0.25	9/16-18	0.66
FF9863-06S	0.38	11/16-16	0.75
FF9863-08S	0.5	13/16-16	0.9
FF9863-10S	0.63	1-14	1
FF9863-12S	0.75	1-3/16-12	1.1
FF9863-16S	1	1-7/16-12	1.17
FF9863-20S	1.25	1-11/16-12	1.17
