main product photo

Steel Adapter, 9/16-18 Male JIC 37 deg Flare To 9/16-18 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

Ask A Question
A
1.64
Alternate Part Numbers
Alternate Part Number C1AY49, Alternate Part Number FMC102-1066, Alternate Part Number MI-00315410, Alternate Part Number MINO-00015F63587
Application
Marine/Military, Chemical Processing, Pulp and Paper Industries, Food and Beverage Processing, Off-Shore Drilling
B
0.83
Drop Dimension
0.83
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Gender 1
13554
End Gender 2
13556
End Size 1
0.56
End Size 2
0.56
End Type 1
SAE 37
End Type 2
SAE 37
Minimum Working Temperature
-65
Supplier Part Number
2042-6-6S
Thread 1
9/16-18
Thread 2
9/16-18
Thread Sealant
No
Tube O.D.
0.38
Tube O.D.
0.38
Product Weight
0.14 lbs
Product Questions & Answers 4

Product Questions & Answers

trying to replace an elbow bulkhead fitting, does this one have 9/16-18 threads on both sides and is it JIC 37 degree flare?
Question by: Gary B on Apr 20, 2025, 11:54 AM
It is a 45 degree elbow bulkhead adapter with 9/16-18 male threads on both ends, and both ends are SAE 37 degree (JIC) flare.
Answer by: Customer Support on Apr 21, 2025, 7:29 PM
what industries is this adapter actually built for? seeing it listed for marine and chemical use but wondering if it holds up in rougher environments
Question by: Curt P on Jul 25, 2025, 6:48 PM
Eaton Aeroquip built this 2042 series adapter for some pretty demanding service conditions. The listed applications cover marine and military use, chemical processing, pulp and paper use, offshore drilling, and food and beverage processing. That covers a wide range of exposure to corrosives, moisture, and mechanical stress, so the material and construction are suited for environments that would chew through lesser fittings. If your operation falls into any of those categories, you're in the right territory.
Answer by: Customer Support on Jul 27, 2025, 4:58 PM
got a tight spot on a bulkhead, is this the 45 elbow that still keeps both ends the same size?
Question by: Rex B on May 5, 2025, 8:38 PM
Built as a 45 degree elbow bulkhead adapter, it keeps the connection size the same on both sides. It is 9/16-18 male JIC 37 degree flare to 9/16-18 male JIC 37 degree flare.
Answer by: Customer Support on May 7, 2025, 4:38 PM
Just wanna make sure, this elbow fitting will work with standard JIC flare fittings, right?
Question by: Diane J on Aug 22, 2025, 11:50 AM
Yes, this elbow adapter is part of the Danfoss / Eaton 2042 series and is designed with SAE 37-degree male flare connections.
Answer by: Customer Support on Aug 24, 2025, 6:43 AM

Similar Products

Model Number Tube O.D. Thread 1 Thread 2 A B Price Buy Now
2042-6-6S 0.38 9/16-18 9/16-18 1.64 0.83
2042-12-12S 0.75 1-1/16-12 1-1/16-12 2.36 1.41
2042-16-16S 1 1-5/16-12 1-5/16-12 2.58 1.47
2042-4-4S 0.25 7/16-20 7/16-20 1.55 0.73
2042-8-8S 0.5 3/4-16 3/4-16 2.08 0.98
2702-LN-04-04-FG 0.25 7/16-20 7/16-20 1.53 0.72
