main product photo

Steel Adapter, 7/16-20 Male JIC 37 deg Flare To 7/16-20 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

Ask A Question
A
1.55
Alternate Part Numbers
Alternate Part Number C1AY48, Alternate Part Number MI-00315400, Alternate Part Number MINO-00015F63585
Application
Marine/Military, Chemical Processing, Pulp and Paper Industries, Food and Beverage Processing, Off-Shore Drilling
B
0.73
Drop Dimension
0.72
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Gender 1
13554
End Gender 2
13556
End Size 1
0.44
End Size 2
0.44
End Type 1
SAE 37
End Type 2
SAE 37
Minimum Working Temperature
-65
Supplier Part Number
2042-4-4S
Thread 1
7/16-20
Thread 2
7/16-20
Thread Sealant
No
Tube O.D.
0.25
Tube O.D.
0.25
Product Weight
0.10 lbs
Product Questions & Answers 3

Product Questions & Answers

Will this here fitting hold up okay if I’m running hydraulic fluid through it on a regular basis?
Question by: Bobby W on May 7, 2025, 12:38 PM
This adapter is well-suited for hydraulic applications. You'll also want to consult the fluid compatibility document to be sure it’s compatible with the specific fluid you intend to use.
Answer by: Customer Support on May 9, 2025, 12:05 PM
Got a bulkhead fitting situation on a marine hydraulic line and need something that'll make a 45-degree turn without a bunch of extra fittings stacked up. this one work for that?
Question by: Chad K on Mar 20, 2026, 1:43 PM
That setup is exactly what this fitting is built around. It's a 45-degree elbow bulkhead configuration with 7/16-20 male JIC 37-degree flare on both ends, so you get the directional change and the bulkhead mount all in one piece. No need to stack a straight bulkhead adapter and a separate elbow. Marine is also one of the listed application environments for this part, so it lines up with what you're working on.
Answer by: Customer Support on Mar 22, 2026, 11:47 AM
trying to replace an old 45 elbow on a bulkhead, is this one 7/16-20 on both ends and JIC 37 flare?
Question by: Phil W on Jul 11, 2025, 5:27 PM
It’s a 45 degree bulkhead elbow adapter with 7/16-20 male JIC 37 degree flare on both sides. That makes it a straight swap when you need male JIC flare to male JIC flare in that same thread size through a bulkhead.
Answer by: Customer Support on Jul 13, 2025, 6:21 AM

Similar Products

Model Number Tube O.D. Thread 1 Thread 2 A B Price Buy Now
2042-6-6S 0.38 9/16-18 9/16-18 1.64 0.83
2042-12-12S 0.75 1-1/16-12 1-1/16-12 2.36 1.41
2042-16-16S 1 1-5/16-12 1-5/16-12 2.58 1.47
2042-4-4S 0.25 7/16-20 7/16-20 1.55 0.73
2042-8-8S 0.5 3/4-16 3/4-16 2.08 0.98
2702-LN-04-04-FG 0.25 7/16-20 7/16-20 1.53 0.72
