Steel Adapter, 1-5/16-12 Male JIC 37 deg Flare To 1-5/16-12 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

A 2.58	Alternate Part Numbers Alternate Part Number C1HH77	Application Marine/Military, Chemical Processing, Pulp and Paper Industries, Food and Beverage Processing, Off-Shore Drilling	B 1.47	Drop Dimension 1.47	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	End Gender 1 13554	End Gender 2 13556	End Type 1 SAE 37	End Type 2 SAE 37	Minimum Working Temperature -65	Supplier Part Number 2042-16-16S	Thread 1 1-5/16-12	Thread 2 1-5/16-12	Thread Sealant No	Tube O.D. 1	Tube O.D. 1	Product Weight 1.06 lbs

Product Questions & Answers 2

Product Questions & Answers

Been looking for a bulkhead elbow to tie into a line on our offshore drilling rig setup. This the right kind of fitting for that application?

Question by: Wayne R on Feb 10, 2026, 9:17 AM

Offshore drilling is one of the listed applications for this fitting, so you're on the right track. It's a 45 degree elbow bulkhead adapter with 1-5/16-12 Male JIC 37 degree flare on both ends, part of the Eaton Aeroquip 2042 Series. The bulkhead design lets it pass through a panel or wall, and the 45 degree angle helps route lines where a straight adapter just won't clear. Both ends are the same thread and flare spec, so your JIC connections on each side need to match that 1-5/16-12 sizing.

Answer by: Customer Support on Feb 11, 2026, 9:37 PM

So this is a 45 degree angle, right? Just want to make sure before I order.

Question by: Rick H on Oct 23, 2025, 4:58 PM

That's correct. This adapter features a 45-degree elbow design.

Answer by: Customer Support on Oct 25, 2025, 12:17 PM

Similar Products

Model Number	Tube O.D.	Thread 1	Thread 2	A	B
2042-6-6S	0.38	9/16-18	9/16-18	1.64	0.83
2042-12-12S	0.75	1-1/16-12	1-1/16-12	2.36	1.41
2042-16-16S	1	1-5/16-12	1-5/16-12	2.58	1.47
2042-4-4S	0.25	7/16-20	7/16-20	1.55	0.73
2042-8-8S	0.5	3/4-16	3/4-16	2.08	0.98
2702-LN-04-04-FG	0.25	7/16-20	7/16-20	1.53	0.72
