Steel Adapter, 1/4-18 Female NPT Swivel To 9/16-18 Male SAE O-Ring Boss (Straight Thread O-Ring), Straight

Ask A Question
A
1.14
Alternate Part Numbers
Alternate Part Number C1AZ75, Alternate Part Number MI-00321819, Alternate Part Number MINO-00015F66128
Application
Marine/Military, Chemical Processing, Pulp and Paper Industries, Food and Beverage Processing, Off-Shore Drilling
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Gender 1
13553
End Gender 2
13556
End Size 1
0.25
End Size 2
0.56
End Type 1
NPSM
End Type 2
SAE ORB
Hex Size 2
0.69
Minimum Working Temperature
-40
Supplier Part Number
2066-4-6S
Thread 1
1/4-18
Thread 2
9/16-18
Thread Sealant
No
Product Weight
0.09 lbs
Product Questions & Answers 3

Product Questions & Answers

got a 1/4-18 female NPT port on a pump and need to connect it to a 9/16-18 SAE O-ring boss fitting, this the right adapter for that?
Question by: Darryl B on Aug 27, 2025, 2:41 PM
That's what this one's built for. The 2066-4-6S bridges a 1/4-18 female NPT swivel end to a 9/16-18 male SAE O-ring boss, straight configuration. The swivel end gives you a little wiggle room during assembly so you're not fighting the line to get everything to line up. It's from Eaton Aeroquip's 2066 series, so the machining and tolerances are consistent with what you'd expect from that line.
Answer by: Customer Support on Aug 29, 2025, 1:15 PM
trying to hook a 1/4-18 female NPT line up to an ORB port, is this the right adapter?
Question by: Earl C on Sep 10, 2025, 12:33 PM
Function-wise it bridges those two thread types in a straight adapter: 1/4-18 female NPT swivel on one end to a 9/16-18 male SAE O-Ring Boss (straight thread O-ring) on the other.
Answer by: Customer Support on Sep 11, 2025, 1:56 PM
Would this adapter work okay in a saltwater environment on a boat?
Question by: Sherry H on Apr 2, 2025, 5:43 PM
These Eaton Aeroquip adapters are often used in marine applications, so it should hold up just fine in a saltwater environment.
Answer by: Customer Support on Apr 3, 2025, 8:29 PM

Similar Products

Model Number Thread 1 Thread 2 A Price Buy Now
2066-16-16S 1-11-1/2 1-5/16-12 1.59
2066-4-4S 1/4-18 7/16-20 1.05
2066-12-12S 3/4-14 1-1/16-12 1.58
2066-4-6S 1/4-18 9/16-18 1.14
2066-6-6S 3/8-18 9/16-18 1.14
2066-6-8S 3/8-18 3/4-16 1.19
2066-8-10S 1/2-14 7/8-14 1.3
2066-8-8S 1/2-14 3/4-16 1.23
6900-06-08-O 1/2-14 9/16-18 1.23
6900-08-04-O 1/4-18 3/4-16 1.22
