Steel Adapter, 0.38 Braze Port To Male O-Ring Face Seal, Straight

A
0.83
Alternate Part Numbers
Alternate Part Number C1EW75
Application
Marine/Military, Chemical Processing, Pulp and Paper Industries, Food and Beverage Processing, Off-Shore Drilling
B
0.25
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Gender 1
13554
End Gender 2
13555
End Size 1
0.69
End Size 2
0.38
End Type 1
ORS
End Type 2
Braze
F
0.38
Minimum Working Temperature
-40
Seal Part if Included
FF9446-12
Supplier Part Number
FF1851T0606S
Thread 2
11/16-16
Thread Sealant
No
Tube O.D.
0.38
Tube O.D.
0.38
Product Weight
0.24 lbs

Product Questions & Answers

what's the tube OD on this fitting? trying to match it up to 3/8 inch tubing on a braze port connection
Question by: Howard P on Apr 4, 2025, 8:58 PM
The braze port end on this adapter is sized for 0.38 inch tube OD, so yes, that lines up with standard 3/8 inch tubing. The other end is a male O-ring face seal at 11/16-16 thread, which is a 6 series ORS connection. Seal part FF9446-12 is included, so you've got what you need to make a complete face seal connection without hunting down a separate o-ring.
Answer by: Customer Support on Apr 6, 2025, 10:03 AM
what industries is this adapter actually built for? trying to make sure it ain't overkill for what we're doing
Question by: Wade L on Sep 10, 2025, 10:43 AM
Eaton Aeroquip built this part with some pretty demanding environments in mind. Listed applications include marine and military use, chemical processing, pulp and paper, food and beverage processing, and offshore drilling. If your operation falls anywhere near those categories, you're well within the intended use range. For lighter-duty or general industrial work, it'll still do the job, but those are the target environments this series was developed around.
Answer by: Customer Support on Sep 11, 2025, 11:37 AM
Will this adapter hold up in a marine environment, you think?
Question by: Steve C on Jun 17, 2025, 9:27 AM
Eaton Aeroquip specifically lists marine applications among the intended uses for this adapter, along with chemical processing and offshore drilling, so it should be suitable.
Answer by: Customer Support on Jun 19, 2025, 6:30 AM
got a line i need to braze in, but the other side has to be a male ORFS. is that what this adapter is for?
Question by: Connie M on Jul 28, 2025, 7:39 PM
You are on the right track. It is a straight steel adapter that goes from a 0.38 braze port on one end to a male O-Ring Face Seal (ORFS) connection on the other, which is a common way to transition from a brazed-in tube connection to an ORFS hydraulic hookup.
Answer by: Customer Support on Jul 30, 2025, 11:47 AM

Similar Products

Model Number Tube O.D. Thread 2 A B F Price Buy Now
FF1851T0606S 0.38 11/16-16 0.83 0.25 0.38
FF1851T0808S 0.5 13/16-16 1.01 0.38 0.5
FF1851T1010S 0.63 1-14 1.12 0.38 0.63
FF1851T1212S 0.75 1-3/16-12 1.21 0.38 0.75
FF1851T1616S 1 1-7/16-12 1.47 0.5 1
