Ss Din X Mbspp No Seal

Adaptall Material Stainless	Adaptall Shape Straight	Side 1 Callout M18 X 1.5	Side 1 Gender M	Side 1 Size L12	Side 1 Type Din Tube	Side 2 Callout G 1/4 - 19	Side 2 Gender M	Side 2 Size 1/4"	Side 2 Type Bspp	Brand Adaptall America	Brand Adaptall	Pack Size 1.00	UOM EA	Supplier Part Number SS5001L-12-04	Product Weight 0.07 lbs

Product Questions & Answers 2

Product Questions & Answers

Got a hydraulic line running DIN tube fittings on one end and need to tie into a BSPP port on a valve block, this adapter do that straight through, no extra fittings needed?

Question by: Melvin B on May 13, 2025, 1:32 PM

Yeah, that's exactly what this one's built for. One side is M18 x 1.5 male DIN tube, the other is G 1/4-19 male BSPP, and it runs straight through with no bends or offsets. As long as your valve block has a female BSPP port sized for 1/4 inch, you're making that conversion in one piece.

Answer by: Customer Support on May 14, 2025, 5:31 PM

got a DIN tube end that’s M18 x 1.5 on one side and i need to land it into a G 1/4-19 port, is this the right adapter?

Question by: Norm J on Jul 18, 2025, 9:07 PM

For thread conversion between those two ends, it matches up as a straight stainless adapter with a DIN tube end M18 x 1.5 male on one side and a male BSPP G 1/4-19 on the other.

Answer by: Customer Support on Jul 20, 2025, 6:29 PM
