Adaptall Ss316 Male Metric X Female Npt SS9235-12-L06-04

Specifications

Adaptall Material Stainless	Adaptall Shape Straight	Side 1 Callout M12 X 1.5	Side 1 Gender M	Side 1 Size L06	Side 1 Type Din Tube	Side 2 Callout 1/4 - 18 NPTF	Side 2 Gender F	Side 2 Size 1/4"	Side 2 Type Npt	Brand Adaptall America	Brand Adaptall	Pack Size 1.00	UOM EA	Supplier Part Number SS9235-12-L06-04	Product Weight 0.10 lbs

Product Questions & Answers 3

Product Questions & Answers

Will this fitting hold up to typical hydraulic pressures without leaking?

Question by: Earl H on May 1, 2025, 4:01 PM

This straight Adaptall fitting is made from stainless steel 316, which offers excellent corrosion resistance and is commonly used in hydraulic applications. The NPT threads should provide a solid seal when properly tightened.

Answer by: Customer Support on May 3, 2025, 8:07 AM

Got a metric tube line on a piece of imported equipment and need to tie it into a 1/4" NPT female port. This fitting do that job?

Question by: Vince M on Mar 9, 2026, 6:34 AM

That's what this one's built for. One end is a male M12 x 1.5 DIN tube connection, size L06, and the other end is a 1/4" female NPT with 1/4-18 NPTF threads. So if you've got a metric DIN tube on one side and a female NPT port on the other, this bridges that gap straight through without any adapters in between.

Answer by: Customer Support on Mar 10, 2026, 8:55 AM

got a line with an M12 x 1.5 DIN tube end, will this screw into a 1/4 npt port on the other side?

Question by: Lynn Y on May 26, 2025, 11:18 AM

It bridges those two standards in one straight adapter. One end is a male M12 x 1.5 DIN tube connection (size L06), and the other end is a 1/4 inch female NPT connection with 1/4 - 18 NPTF threads.

Answer by: Customer Support on May 28, 2025, 6:52 AM
