SBV11-12-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Coil Not Included	Coil Special Features None	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Installation Type Screw-in Cartridge	Leakage Standard	Manual Override Option No	Number of Housing Ports 2	Number of Valve Ports 2	Operation Direct Acting	Port Type Cartrige Only	Recommended Filtration Level 18/16/13	Seal Material Buna-N	Seal Type Buna-N	Special Features None	Style Bi-Directional 2-Way 2-Position Normally Closed	Supplier Part Number 02-177576	Switch Connector No	Valve Material Cartridge only	Product Weight 0.60 lbs	Alternate Part Numbers Alternate Part Number C1LW47, Alternate Part Number SBV1112C000

Product Questions & Answers 3

Product Questions & Answers

runs at 5000 psi all day long on a refuse hauler, will internal leakage be a problem over time?

Question by: Howard B on Jan 4, 2026, 2:21 PM

At full rated pressure, maximum internal leakage on this valve is 5 drops per minute. For a refuse hauler running continuous duty at high pressure, that's a pretty tight spec and should hold up well under normal operating conditions. The cartridge body is hardened and ground steel, so it's not going to wear fast on the internal seating surfaces. Keep your fluid clean at ISO 4406 level 18/16/13 or better and you'll get the most life out of it.

Answer by: Customer Support on Jan 5, 2026, 9:24 PM

got a valve bank that’s already cut for a C-12-2 cavity. will this SBV11-12-C screw right in, or am i missing something?

Question by: Terry J on Apr 10, 2025, 3:52 PM

It’s a screw-in cartridge built for the C-12-2 cavity size, and it does require a machined cavity or housing to install. Keep in mind this SKU is the cartridge only, so the housing is sold separately and the coil is not included.

Answer by: Customer Support on Apr 12, 2025, 6:34 AM

Will this valve work in my harvester without a separate housing?

Question by: Roger R on Oct 30, 2025, 5:01 PM

No, this solenoid cartridge valve requires a machined cavity or housing for installation, specifically a C-12-2 size. It's sold separately.

Answer by: Customer Support on Nov 1, 2025, 7:56 AM

Similar Products

Part Number	Model Number	Housing	Coil	Seal Material	Price	Buy Now
02-177576	SBV11-12-C-0-00	None	Not Included	Buna-N
