PRV2-10 Series Pilot-Operated Pressure Reducing (Relieving) Cartridge Valves, Up To 10 GPM & 3500 PSI

Application	This valve is normally open, allowing flow from port 2 to port 1. Port 3 is a drain and must be vented back to reservoir. Once the pressure setting is reached at port 1, the spool shifts to restrict the inlet flow at port 2. This regulates the pressure at port 1. If pressure at port 1 exceeds the predetermined setting of the valve, the spool will shift further and relieve excess pressure through port 3.
Cartridge	Model PRV2-10*, sold separately.
Features	The PRV2-10 is a pilot operated, spool type screw-in cartridge pressure reducing/relieving valve, and requires a machined cavity or housing for installation.
Flow Rating	10 GPM.
Housing	Cavity size C-10-3, sold separately, see
Pressure Rating	3500 PSI All ports (CAUTION: Pressures over 3000 PSI require steel housing).
Recommended Filtration	ISO 4406 Cleanliness Level 18/16/13 or cleaner.
Temperature Range	-40°F to 248°F (Extreme Limits).

Products

Part Number	Model Number	Adjustment Style	Cracking Pressure (psi)	Pressure Setting	Housing	Seal Material	Price	Buy Now
02-170743	PRV2-10-S-0-35/25	Screw and locknut	250-3500	2500	None	Buna-N
