Precision Splined Hub, 13 Tooth SAE D, 8/16 DP, 30° PA, 1-3/4 O.D. Spline, 3.00 Inch OD, 2.25 Inch Long

Brand MOTION INDUSTRIES INC - IS22	Brand Motion Industries	Pack Size 1.00	UOM EA	Length 2.25	O.D. 3 in	Spline Details 8/16 DP, 30° PA, 1-3/4 O.D.	Supplier Part Number 0332-00074	Type 13 Tooth SAE D	Alternate Part Numbers Alternate Part Number 0332-00074, Alternate Part Number C1AD63	Product Weight 6.00 lbs

Product Questions & Answers 2

Product Questions & Answers

what's the spline spec on this hub, is it really a standard SAE D setup or something proprietary?

Question by: Lance C on Apr 26, 2025, 8:18 AM

Fully standard SAE D configuration. The spline runs 13 teeth at 8/16 diametral pitch with a 30 degree pressure angle and a 1-3/4 inch O.D. spline. That matches the SAE D spec you'd find on most pumps and motors calling for that interface, so nothing unusual or custom about it.

Answer by: Customer Support on Apr 28, 2025, 8:00 AM

What kind of steel is this hub made out of?

Question by: Troy J on May 10, 2025, 8:09 AM

It's made from a low alloy, high carbon steel, so it should hold up well in demanding applications.

Answer by: Customer Support on May 11, 2025, 8:16 PM

Similar Products

Model Number	Type	Spline Details	O.D.	Length
03-32-00032	9 Tooth SAE A	16/32 DP, 30° PA, 5/8 O.D.	1.25 in	1.250
03-32-00033	13 Tooth SAE B	16/32 DP, 30° PA, 7/8 O.D.	1.5 in	1.50
03-32-00034	14 Tooth SAE C	12/24 DP, 30° PA, 1-1/4 O.D.	2.25 in	2.00
03-32-00074	13 Tooth SAE D	8/16 DP, 30° PA, 1-3/4 O.D.	3 in	2.25
