Precision Splined Hub, 9 Tooth SAE A, 16/32 DP, 30° PA, 5/8 O.D. Spline, 1.25 Inch OD, 1.250 Inch Long

Brand MOTION INDUSTRIES INC - IS22	Brand Motion Industries	Pack Size 1.00	UOM EA	Length 1.25	O.D. 1.25 in	Spline Details 16/32 DP, 30° PA, 5/8 O.D.	Supplier Part Number 0332-00032	Type 9 Tooth SAE A	Alternate Part Numbers Alternate Part Number 0332-00032, Alternate Part Number C1EX23, Alternate Part Number MI-00891492, Alternate Part Number MINO-00435X10761	Product Weight 0.34 lbs

Product Questions & Answers 2

Product Questions & Answers

does this hub work with a 9 tooth SAE A spline shaft, or is that just the hub configuration itself?

Question by: Kurt J on Nov 29, 2025, 3:38 PM

The 9 tooth SAE A spec describes the spline configuration on the hub, so yes, it's built to mate with a matching 9 tooth SAE A splined shaft. The spline details are 16/32 diametral pitch with a 30 degree pressure angle and a 5/8 inch outer diameter spline. As long as your shaft matches those specs, you're in good shape for a proper fit.

Answer by: Customer Support on Dec 1, 2025, 1:11 PM

What's the OD on the spline itself? Just want to make sure it'll fit my setup.

Question by: Shawn B on Jun 30, 2025, 10:39 AM

The outer diameter of the spline is 5/8 inch.

Answer by: Customer Support on Jul 2, 2025, 7:54 AM

Similar Products

Model Number	Type	Spline Details	O.D.	Length
03-32-00032	9 Tooth SAE A	16/32 DP, 30° PA, 5/8 O.D.	1.25 in	1.250
03-32-00033	13 Tooth SAE B	16/32 DP, 30° PA, 7/8 O.D.	1.5 in	1.50
03-32-00034	14 Tooth SAE C	12/24 DP, 30° PA, 1-1/4 O.D.	2.25 in	2.00
03-32-00074	13 Tooth SAE D	8/16 DP, 30° PA, 1-3/4 O.D.	3 in	2.25
