Polyethylene Tubing, 0.13 OD, 0.03 Thick, 0.06 ID, Up To 305.00 PSI

Burst Pressure 1220	Color Natural	Brand Freelinwade	Brand Freelinwade	Pack Size 12.00	UOM FT	I.D. 0.062 in	Maximum Operating Pressure 305	Minimum Bend Radius 0.50	Minimum Bend Radius 0.5	O.D. 0.125 in	Package Qty. 100	Supplier Part Number 1J-109-10	Wall Thickness 0.03	Alternate Part Numbers Alternate Part Number C1MJ15, Alternate Part Number MI-08754694, Alternate Part Number MINO-00326X98754	Product Weight 0.01 lbs

Product Questions & Answers 1

Product Questions & Answers

got a tight little run on a panel, how sharp can i bend this tubing without kinking it?

Question by: Johnny M on Apr 25, 2025, 2:30 PM

For tight routing, the minimum bend radius is 0.5 inches. Staying at or above that bend radius helps keep the tube from flattening out and also reduces stress at the bend.

Answer by: Customer Support on Apr 27, 2025, 8:06 AM

Similar Products

Model Number	O.D.	Wall Thickness	I.D.	Minimum Bend Radius	Color	Maximum Operating Pressure	Burst Pressure	Package Qty.
1J-048-01	0.25 in	0.04	0.17 in	1.25	Black	200	800	100
1J-048-10	0.25 in	0.04	0.17 in	1.25	Natural	200	800	100
1J-074-10	0.375 in	0.062	0.25 in	2	Natural	190	760	100
1J-077-10	0.313 in	0.062	0.187 in	1.5	Natural	230	920	100
1J-109-10	0.125 in	0.031	0.062 in	0.5	Natural	305	1220	100
A43184	0.188 in	0.031	0.125 in	1	Natural	200	800	100
