Polyethylene Tubing, 0.31 OD, 0.06 Thick, 0.19 ID, Up To 230.00 PSI

Burst Pressure 920	Color Natural	Brand Freelinwade	Brand Freelinwade	Pack Size 12.00	UOM FT	I.D. 0.187 in	Maximum Operating Pressure 230	Minimum Bend Radius 1.50	Minimum Bend Radius 1.5	O.D. 0.313 in	Package Qty. 100	Supplier Part Number 1J-077-10	Wall Thickness 0.06	Alternate Part Numbers Alternate Part Number C1MM35, Alternate Part Number MI-04517652, Alternate Part Number MINO-00326X00017	Product Weight 0.01 lbs

Product Questions & Answers 1

Product Questions & Answers

got a 5/16 line now, is this the same size or am i gonna be fighting it on the fittings

Question by: Terry G on Nov 6, 2025, 3:53 PM

You are looking at 5/16 inch OD tubing. The outside diameter is 0.313 in and the inside diameter is 0.187 in with a 0.062 in wall, so it matches what most folks mean when they say 5/16 OD.

Answer by: Customer Support on Nov 8, 2025, 6:48 AM

Similar Products

Model Number	O.D.	Wall Thickness	I.D.	Minimum Bend Radius	Color	Maximum Operating Pressure	Burst Pressure	Package Qty.
1J-048-01	0.25 in	0.04	0.17 in	1.25	Black	200	800	100
1J-048-10	0.25 in	0.04	0.17 in	1.25	Natural	200	800	100
1J-074-10	0.375 in	0.062	0.25 in	2	Natural	190	760	100
1J-077-10	0.313 in	0.062	0.187 in	1.5	Natural	230	920	100
1J-109-10	0.125 in	0.031	0.062 in	0.5	Natural	305	1220	100
A43184	0.188 in	0.031	0.125 in	1	Natural	200	800	100
