L2 Series Gear Pump, 2.33 cu in/rev, 2-Bolt SAE B Mounting Flange, 7/8 Straight Keyed Shaft, SAE-20 Side Inlet, SAE-12 Side Outlet Ports, CW Rotation.

Application Agricultural, Civil Engineering, Primary metals, Material handling, Speciality Construction, Metal Forming, Natural Resources	Configuration 32	Design Code A	Displacement 2.33	Displacement 2.33	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	Identification Standard	Minimum Working Temperature -20	Mount 2-Bolt SAE B	Mount 2-Bolt SAE B	Ports SAE-20 Side Inlet, SAE-12 Side Outlet	Ports SAE-20 Side Inlet, SAE-12 Side Outlet	Pressure Rating 3600	Rated Flow 18.10	Rated Flow 18.1	Rotation CW	Shaft 7/8 Straight Keyed	Shaft 7/8 Straight Keyed	Special Features None	Speed Rating 2750 RPM	Speed Rating 2750 RPM	Supplier Part Number 25504-RSC	Alternate Part Numbers Alternate Part Number C1JY12	Product Weight 15.00 lbs

Product Questions & Answers 2

Product Questions & Answers

What kind of machines would you typically find this gear pump on?

Question by: Stan P on Jul 26, 2025, 12:06 PM

You'll find this L2 series gear pump used in agricultural equipment, civil engineering projects, material handling systems, specialty construction, metal forming, and even natural resource extraction applications.

Answer by: Customer Support on Jul 28, 2025, 6:44 AM

pump says CW rotation on the tag, but I need it to spin the other way for my setup, is that something that can be changed out in the field or do I need a whole different unit?

Question by: Rusty W on Mar 1, 2026, 9:05 PM

Field reversible pump direction is actually a listed feature on this L2 Series, so you're not stuck buying a separate unit just to flip the rotation. That's a nice flexibility to have when you're retrofitting into an existing system that was plumbed the opposite way.

Answer by: Customer Support on Mar 3, 2026, 8:19 AM

Similar Products

Model Number	Displacement	Rated Flow	Mount	Shaft	Ports	Rotation	Features	Speed Rating	Pressure Rating
25501-RSC	1.55	12	2-Bolt SAE B	7/8 Straight Keyed	SAE-20 Side Inlet, SAE-12 Side Outlet	CW	Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	3000 RPM	3600
25503-RSA	2.05	15.9	2-Bolt SAE B	13 Tooth SAE B Splined	SAE-20 Side Inlet, SAE-12 Side Outlet	CW	Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	2750 RPM	3600
25504-LSC	2.33	18.1	2-Bolt SAE B	7/8 Straight Keyed	SAE-20 Side Inlet, SAE-12 Side Outlet	CCW	Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	2750 RPM	3600
25504-RSC	2.33	18.1	2-Bolt SAE B	7/8 Straight Keyed	SAE-20 Side Inlet, SAE-12 Side Outlet	CW	Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	2750 RPM	3600
