L2 Series Gear Pump, 2.33 cu in/rev, 2-Bolt SAE B Mounting Flange, 7/8 Straight Keyed Shaft, SAE-20 Side Inlet, SAE-12 Side Outlet Ports, CCW Rotation.

Application Agricultural, Civil Engineering, Primary metals, Material handling, Speciality Construction, Metal Forming, Natural Resources	Configuration 32	Displacement 2.33	Displacement 2.33	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	Identification Standard	Minimum Working Temperature -20	Mount 2-Bolt SAE B	Mount 2-Bolt SAE B	Ports SAE-20 Side Inlet, SAE-12 Side Outlet	Ports SAE-20 Side Inlet, SAE-12 Side Outlet	Pressure Rating 3600	Rated Flow 18.10	Rated Flow 18.1	Rotation CCW	Shaft 7/8 Straight Keyed	Shaft 7/8 Straight Keyed	Special Features None	Speed Rating 2750 RPM	Speed Rating 2750 RPM	Supplier Part Number 25504-LSC	Alternate Part Numbers Alternate Part Number C1JY11	Product Weight 15.00 lbs

Product Questions & Answers

Will this pump work for a log splitter application?

Question by: Brenda H on Nov 15, 2025, 8:18 AM

Eaton Char-Lynn L2 series gear pumps are frequently used in material handling and specialty construction, including log splitters.

Answer by: Customer Support on Nov 17, 2025, 6:47 AM

got a setup that needs a 2-bolt SAE B mount and a 7/8 straight keyed shaft. is that what this pump comes with?

Question by: Freddie C on Oct 2, 2025, 6:35 PM

It matches a 2-bolt SAE B mounting flange and a 7/8 straight keyed shaft, so those two interface points line up with what you described.

Answer by: Customer Support on Oct 4, 2025, 6:07 AM

Model Number	Displacement	Rated Flow	Mount	Shaft	Ports	Rotation	Features	Speed Rating	Pressure Rating
25501-RSC	1.55	12	2-Bolt SAE B	7/8 Straight Keyed	SAE-20 Side Inlet, SAE-12 Side Outlet	CW	Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	3000 RPM	3600
25503-RSA	2.05	15.9	2-Bolt SAE B	13 Tooth SAE B Splined	SAE-20 Side Inlet, SAE-12 Side Outlet	CW	Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	2750 RPM	3600
25504-LSC	2.33	18.1	2-Bolt SAE B	7/8 Straight Keyed	SAE-20 Side Inlet, SAE-12 Side Outlet	CCW	Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	2750 RPM	3600
25504-RSC	2.33	18.1	2-Bolt SAE B	7/8 Straight Keyed	SAE-20 Side Inlet, SAE-12 Side Outlet	CW	Reduced noise and vibration\|Improved volumetric and mechanical efficiency\|Field reversible pump direction	2750 RPM	3600
