Metric Nylon Tubing 8MM O.D. IGMTP16008NA-100

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number C1HB71	Application Resistant to most chemicals and hydrocarbons.	Color Natural	Conductivity 30	Construction Extruded	Cover Material Polyamide	Dash Size -8	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM FT	Features UV resistance last longer than all competitors\|Hundreds of styles to choose from\|Rugged enough to stand up to the toughest applications	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 2.25	Minimum Bend Radius 2.25	Minimum Working Temperature -40	Net Pack Quantity Units FT	NMFC 70	Product Width 0.32	Qualified Hose Fittings Metric Push to Connect	Reinforcement Material Polyamide	Sub Brand Weatherhead	Supplier Part Number MTP16008NA-100	Tube Material Polyamide	Product Weight 0.04 lbs

Product Questions & Answers 3

Product Questions & Answers

What kind of stuff is this tubing good for resisting?

Question by: Neil M on Sep 28, 2025, 2:03 PM

Built with premium polyamide, the tubing offers exceptional abrasion resistance and is resistant to most chemicals and hydrocarbons.

Answer by: Customer Support on Sep 30, 2025, 6:11 AM

Does this tubing hold up outside in the sun and heat? Running it on equipment that sits out year-round and had problems with other tubing cracking on me.

Question by: Wade G on Jun 24, 2025, 3:21 PM

UV resistance is one of the stronger points of this tubing. The polyamide construction handles sunlight exposure better than a lot of competing products, and the rated temperature range bottoms out at -40C so cold snaps aren't a concern either. For outdoor equipment that goes through seasonal swings, it tends to outlast standard tubing options pretty reliably.

Answer by: Customer Support on Jun 26, 2025, 7:51 AM

got a tight spot to run line, how sharp can i bend this 8mm nylon tubing without kinking it

Question by: Rex G on Mar 23, 2026, 9:30 PM

Minimum bend radius on this tubing is 2.25, so you will want to keep your bends at or above that radius for a clean run.

Answer by: Customer Support on Mar 25, 2026, 1:28 PM
