WEATHERHEAD H470 HYDRAULIC HOSE. IGH47120

Specifications

Abrasion Resistance 28	Application Hydraulics system service wirh petroleum and water based fluids, for general use	Certifications EN856 Type R13\|SAE 100R13	Class WEB-ITEM	Color Black	Compliances MSHA Approved\|USCG\|ABS Certified	Construction Multi Spiral	Cover Material Nitrile	Dash Size -20	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM FT	Features Maximum durability under harsh operating conditions\|Robust construction able to withstand highest pressures\|System engineered to extend hose assembly life	ICC Hoses and Flexible Tubes	Impulse Cycle Life 1000000 cycle	Language English	Lay Line Style Embossed	Minimum Bend Radius 8.25	Minimum Bend Radius 8.25	Minimum Working Temperature -40	Product Width 1.85	Qualified Hose Fittings 6S	Reinforcement Material Wire	Supplier Part Number H47120	Tube Material Nitrile	Product Weight 84.00 lbs

Product Questions & Answers 3

Product Questions & Answers

Reckon this hose'll hold up if I'm usin' it for hydraulics with water-based fluids? Don't wanna get the wrong thing.

Question by: Pete S on Oct 5, 2025, 6:32 AM

This Weatherhead H470 hydraulic hose is made to handle petroleum and water-based fluids, so you should be good to go. It's versatile for different industrial jobs.

Answer by: Customer Support on Oct 7, 2025, 6:34 AM

Does this hose hold up in real dirty conditions, like heavy equipment running all day out in the field? I need something that ain't gonna wear through on me quick.

Question by: Kurt G on Sep 19, 2025, 5:58 PM

Premium abrasion resistance on the nitrile cover is one of the main selling points of the H470. The black nitrile cover is built to take regular punishment without breaking down ahead of schedule, so on equipment that runs hard and sits in rough environments, it holds up considerably better than standard cover materials. The multi-spiral wire reinforcement also keeps the hose from fatiguing under repeated pressure cycles, rated out to one million impulse cycles, which matters a lot on machines that cycle constantly throughout a shift.

Answer by: Customer Support on Sep 20, 2025, 7:13 PM

i need a hose that’ll take a beating on the outside, what’s the cover on this Weatherhead H470 made of?

Question by: Vince E on Mar 6, 2026, 8:29 AM

For abrasion-heavy spots, the H470 uses a black nitrile cover with premium abrasion resistance, so it holds up well when the hose is rubbing or getting scuffed in service.

Answer by: Customer Support on Mar 7, 2026, 12:11 PM
