HI-IMPULSE Matchmate Blue Single Wire Braid SAE 100R1AT Type S Hose, 0.38 Inch ID, Up To 3000.00 PSI

Abrasion Resistance 29	Application Hydraulics, crude, fuel and lubricating oils, gasoline, water and phosphate ester base hydraulic fluids	Color Blue	Conductivity 30	Construction 1 Ply Braid	Cover Material Elastomer	Dash Size -6	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Hose I.D. 0.38	Hose O.D. 0.69	Impulse Cycle Life 400000 cycle	Lay Line Style Embossed	Maximum Operating Pressure 3000	Minimum Bend Radius 4.92	Minimum Bend Radius 4.92	Minimum Working Temperature -40	Reel Qty (ft) 450-550	Reinforcement Material Wire	Supplier Part Number GH194-6	Tube Material AQP Inner tube	Alternate Part Numbers Alternate Part Number C1KM12, Alternate Part Number MI-01461942, Alternate Part Number MINO-00015J20093	Product Weight 0.62 lbs

Product Questions & Answers 2

Product Questions & Answers

will this handle 3000 psi continuous or is that just a max rating

Question by: Larry P on Sep 4, 2025, 11:41 AM

At 3000 PSI, you're right at the upper limit for this hose. SAE 100R1AT specifications typically indicate maximum working pressure rather than continuous duty ratings, so running it consistently at that full 3000 PSI could reduce service life. Most hydraulic applications see pressure fluctuations anyway, but if you're looking at steady high-pressure operation, you'd want to factor in a safety margin below that maximum rating.

Answer by: Customer Support on Sep 5, 2025, 12:14 PM
