Danfoss / Eaton;Danfoss / Eaton;Hose SiliconeSaeJ20 Red;FF90829-56;Hose SiliconeSaeJ20 Red;Working Pressure 40 PSI FF90829-56

Specifications

Abrasion Resistance 28	Application High temperature vibration isolation for air aspiration units.	Certifications SAE J20	Color Red	Conductivity 30	Construction 4 Ply	Cover Material Silicone	Dash Size -56	Brand Danfoss (Aeroquip Inc-Industrial Hose)	Brand Aeroquip	Pack Size 1.00	UOM EA	Features Highly abrasion resistant cover\|Small number of hoses for many fuel options\|Proven reliability with high temperature resistance	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 6.50	Minimum Bend Radius 6.5	Minimum Working Temperature -54	Net Pack Quantity Units EA	NMFC 70	Product Width 3.89	Reinforcement Material Aramid	Sub Brand None	Supplier Part Number FF90829-56	Tube Material Silicone	Product Weight 0.14 lbs

Product Questions & Answers 2

Product Questions & Answers

What kind of temps can this hose handle on the low end? We run equipment through some pretty brutal winters and need something that ain't gonna get stiff and crack on us.

Question by: Gary M on May 21, 2025, 2:16 PM

Rated down to negative 54 degrees, so cold-weather cracking shouldn't be a concern in most operating environments. The silicone construction holds up well in temperature extremes on both ends, which is part of why it gets used in high-temperature air aspiration setups to begin with. For winter operation, that lower limit gives you solid headroom.

Answer by: Customer Support on May 23, 2025, 6:55 AM

got a tight spot on an air aspiration setup, how sharp can i bend this hose without kinkin it up

Question by: Neil F on May 19, 2025, 2:35 PM

Minimum bend radius on the FF90829-56 is 6.5 inches. Staying at or above that bend radius helps it hold its shape and avoid kinks.

Answer by: Customer Support on May 20, 2025, 9:58 PM
