main product photo

Nylon Air Brake Tubing, Blue, 0.25 Inch OD, 0.04 Inch Wall Thickness, 1000 Feet Per Pack

Ask A Question
Abrasion Resistance
28
Application
Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.
Color
Blue
Conductivity
13552
Construction
Extruded
Cover Material
UV Stabilized
Dash Size
-4
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
I.D.
0.17 in
Lay Line Style
Ink Jet
Minimum Bend Radius
1
Minimum Bend Radius
1
Minimum Working Temperature
-40
O.D.
0.25 in
Package Qty.
1000
Reinforcement Material
None
Supplier Part Number
4247-0416-1000
Tube Material
Polyamide Alloy
Type
A
Wall Thickness
0.04
Alternate Part Numbers
Alternate Part Number C1MJ96
Product Weight
0.03 lbs
Product Questions & Answers 3

Product Questions & Answers

tubing rated for cold weather use? got routes that see some pretty nasty winters and need something that aint gonna get stiff and crack on me
Question by: Randy S on Sep 1, 2025, 2:11 PM
Cold performance is solid on this one. The operating range runs down to -65 degrees F, so freezing temps and hard winters are well within what it handles. The polyamide alloy construction also holds up to abrasion and flexing, which matters when lines shift and vibrate in cold conditions. For truck and trailer air brake systems running through rough seasonal changes, this tubing is built to stay functional across that whole temperature swing.
Answer by: Customer Support on Sep 3, 2025, 6:00 AM
need to run new line on a trailer, is this the right stuff for air brakes or is it just generic air tubing?
Question by: Eddie C on Oct 9, 2025, 11:01 AM
Built for truck and trailer air brake systems, this nylon tubing is also used on auxiliary air systems and air brake harness assemblies. It meets SAE J844, J1131, and J2494-3 plus DOT-FMVSS 106 performance standards, so it is aimed at air brake use, not just general shop air.
Answer by: Customer Support on Oct 10, 2025, 7:43 PM
What's the smallest radius this tubing can bend without kinking? I'm workin' in a tight spot.
Question by: Marvin C on Jul 1, 2025, 3:08 PM
The minimum bend radius for this blue nylon air brake tubing is 1 inch.
Answer by: Customer Support on Jul 3, 2025, 6:30 AM

Similar Products

Model Number Type O.D. Wall Thickness I.D. Minimum Bend Radius Color Burst Pressure Package Qty. Price Buy Now
3270-0610-0100 B 0.375 in 0.06 0.25 in 1.5 Black 100
3270-0610-0500 B 0.375 in 0.06 0.25 in 1.5 Black 500
3270-0612-0500 B 0.375 in 0.06 0.25 in 1.5 Red 500
3270-0613-0500 B 0.375 in 0.06 0.25 in 1.5 Orange 500
3270-0614-0500 B 0.375 in 0.06 0.25 in 1.5 Yellow 500
3270-0615-0500 B 0.375 in 0.06 0.25 in 1.5 Green 500
3270-0616-0500 B 0.375 in 0.06 0.25 in 1.5 Blue 500
3270-0810-0100 B 0.5 in 0.06 0.38 in 2 Black 100
3270-0810-0500 B 0.5 in 0.06 0.38 in 2 Black 500
3270-08104 B 0.5 in 0.06 0.38 in 2 Black 1500
3270-0812-0500 B 0.5 in 0.06 0.38 in 2 Red 500
3270-08124 B 0.5 in 0.06 0.38 in 2 Red 1500
3270-0815-0500 B 0.5 in 0.06 0.38 in 2 Green 500
3270-1010-0250 B 0.625 in 0.09 0.44 in 2.5 Black 250
3270-10103 B 0.625 in 0.09 0.44 in 2.5 Black 750
3270-1012-0250 B 0.625 in 0.09 0.44 in 2.5 Red 250
3270-1013-0250 B 0.625 in 0.09 0.44 in 2.5 Orange 250
3270-1015-0250 B 0.625 in 0.09 0.44 in 2.5 Green 250
3270-1016-0250 B 0.625 in 0.09 0.44 in 2.5 Blue 250
3270-1210-0250 B 0.75 in 0.09 0.57 in 3 Black 250
3270-1215-0250 B 0.75 in 0.09 0.57 in 3 Green 250
4245-0220-1000 A 0.125 in 0.02 0.08 in 1.25 Black 1000
4245-0520-0500 A 0.313 in 0.04 0.23 in 1.13 Black 500
4247-0410-0100 A 0.25 in 0.04 0.17 in 1 Black 100
4247-0410-1000 A 0.25 in 0.04 0.17 in 1 Black 1000
4247-0412-1000 A 0.25 in 0.04 0.17 in 1 Red 1000
4247-0413-1000 A 0.25 in 0.04 0.17 in 1 Orange 1000
4247-0414-1000 A 0.25 in 0.04 0.17 in 1 Yellow 1000
4247-0415-1000 A 0.25 in 0.04 0.17 in 1 Green 1000
4247-0416-1000 A 0.25 in 0.04 0.17 in 1 Blue 1000
