main product photo

Nylon Air Brake Tubing, Green, 0.25 Inch OD, 0.04 Inch Wall Thickness, 1000 Feet Per Pack

Ask A Question
Abrasion Resistance
28
Application
Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.
Color
Green
Conductivity
13552
Construction
Extruded
Cover Material
UV Stabilized
Dash Size
-4
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
I.D.
0.17 in
Lay Line Style
Ink Jet
Minimum Bend Radius
1
Minimum Bend Radius
1
Minimum Working Temperature
-40
O.D.
0.25 in
Package Qty.
1000
Reinforcement Material
None
Supplier Part Number
4247-0415-1000
Tube Material
Polyamide Alloy
Type
A
Wall Thickness
0.04
Alternate Part Numbers
Alternate Part Number C1MJ95
Product Weight
0.03 lbs
Product Questions & Answers 3

Product Questions & Answers

got a trailer harness that takes -4 line. is this the right size tubing for that?
Question by: Shane H on May 20, 2025, 5:15 PM
It’s -4 dash tubing with a 0.25 inch outside diameter and a 0.04 inch wall, so it matches the common -4 size callout used in air brake harness assemblies.
Answer by: Customer Support on May 22, 2025, 10:47 AM
What kind of temperatures can this green tubing handle?
Question by: Rusty C on Jan 21, 2026, 8:13 PM
This tubing is rated to handle temperatures ranging from -65°F to 200°F.
Answer by: Customer Support on Jan 23, 2026, 6:35 AM
tubing says it meets SAE J844 and DOT-FMVSS 106 -- does that cover both truck and trailer brake systems or just one or the other
Question by: Brent S on Jul 27, 2025, 9:32 PM
Both are covered. Those standards apply across truck and trailer air brake systems, and this tubing is rated for use in both. It also works for auxiliary air systems and formed or straight air brake harness assemblies, so it handles the full range of typical brake line applications on a rig.
Answer by: Customer Support on Jul 29, 2025, 9:10 AM
