Clearforce Reinforced Standard Duty PVC Hose, 1.69 Inch OD, 1.25 Inch ID, Up To 100.00 PSI

Abrasion Resistance 28	Application For food and beverage dispensing, powdered food manufacturing, water and bilge lines, washdown hose, in-plant air and water service and spraying and conveying fertilizers and pesticides.	Color Clear	Construction Extruded	Cover Material PVC	Dash Size -20	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM FT	I.D. 1.25 in	Lay Line Style Ink Jet	Maximum Working Pressure 100	Minimum Working Temperature 15	O.D. 1.688 in	Package Qty. 100	Reinforcement Material Fiber	Supplier Part Number H28520-100	Tube Material Polyvinyl Chloride (PVC)	Alternate Part Numbers Alternate Part Number C1KW18	Product Weight 0.22 lbs

Product Questions & Answers 1

Product Questions & Answers

trying to run a washdown line in the shop. is this hose gonna stay flexible when it gets cold, or does it turn stiff on me?

Question by: Neal A on Oct 6, 2025, 4:33 PM

For temperature, it is rated to operate from +15°F up to +150°F. Within that range it is meant to stay flexible and easy to handle, and the PVC construction is lightweight and nonmarking.

Answer by: Customer Support on Oct 8, 2025, 9:27 AM

Similar Products

Model Number	I.D.	O.D.	Maximum Working Pressure	Minimum Bend Radius	Package Qty.
H28504-125R	0.25 in	0.45 in	250	1	125
H28506-300R	0.38 in	0.59 in	225	1.25	300
H28508-300R	0.5 in	0.75 in	200	2	300
H28510-300R	0.625 in	0.875 in	200	2.5	300
H28512-300R	0.75 in	1.031 in	150	2.5	300
H28516-200R	1 in	1.313 in	125	3.5	200
H28520-100	1.25 in	1.688 in	100		100
H28524-100	1.5 in	1.938 in	100		100
