Bspp Test Port X 1/4" Bspp

CH1 Width 41mm	CH2 Width 41mm	L Length 66mm	Adaptall Material Steel	Adaptall Shape Tee	Side 1 Callout G 1 - 11	Side 1 Gender M	Side 1 Size 1"	Side 1 Type Bspp	Side 2 Callout G 1 - 11	Side 2 Gender F	Side 2 Size 1"	Side 2 Type Bspp	Side 3 Callout G 1/4 - 19	Side 3 Gender F	Side 3 Size 1/4"	Side 3 Type BSPP	Brand Adaptall America	Brand Adaptall	Pack Size 1.00	UOM EA	Supplier Part Number 9015TP-16-16-B04	Product Weight 0.80 lbs

Product Questions & Answers 1

Product Questions & Answers

need a way to check pressure without tearing my 1 inch BSPP line apart. is this the kind of tee that gives you a test port?

Question by: Floyd M on Dec 9, 2025, 2:35 PM

Built as an in-line tee, it keeps your main 1 inch BSPP flow path going from the G 1-11 male side into the G 1-11 female side, and the third leg is a dedicated G 1/4-19 female BSPP port so you can hook up a gauge or diagnostic connection point without interrupting the main circuit.

Answer by: Customer Support on Dec 11, 2025, 10:32 AM
