Steel Adapter, 0.63 Braze Tube To 1-14 Female O-Ring Face Seal Nut

A 0.92	Alternate Part Numbers Alternate Part Number C1EP97, Alternate Part Number MI-00444209, Alternate Part Number MINO-00015I00776	E 0.83	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM EA	Finish Zinc Clear Trivalent Chromate	Materials Carbon steel	Series FC2326	Supplier Part Number FC2326-10S	Thread 1 1-14	Thread Sealant No	Tube O.D. 0.63	Tube O.D. 0.63	Type Swivel Nuts	Product Weight 0.10 lbs

Product Questions & Answers 1

Product Questions & Answers

got a braze tube fitting coming off a busted hydraulic line and need to know if this nut will match up to a 1-14 female O-ring face seal connection, that right?

Question by: Tammy P on Oct 23, 2025, 8:29 PM

Yeah, that's exactly what this part does. The FC2326-10S connects a 0.63 inch braze tube on one end to a 1-14 female O-ring face seal nut on the other. The A dimension comes in at 0.92 inches, so as long as your braze tube is 0.63 and your mating connection is a 1-14 ORFS, you're working with the right part.

Answer by: Customer Support on Oct 25, 2025, 10:33 AM

Similar Products

Model Number	Tube O.D.	Thread 1	A	E
FC2326-06S	0.38	11/16-16	0.67	0.53
FC2326-08S	0.5	13/16-16	0.83	0.65
FC2326-10S	0.63	1-14	0.92	0.83
FC2326-16S	1	1-7/16-12	1.1	1.14
